Chapter 4 Settings — [PROJECTOR SETUP] menu
ENGLISH - 143
3) Press qw to switch the pages.
f The page will change each time you press the button.
[PROJECTOR TYPE] Displays the projector type and serial number of the projector.
[PROJECTOR RUNTIME] Displays the runtime of the projector.
[LIGHT RUNTIME] Displays the runtime of the light source 1 and the light source 2.
[MAIN/SUB VERSION] Displays the main and sub versions of the rmware of the projector.
[INTAKE AIR TEMP.]
*1
Displays the status of the intake air temperature of the projector.
[OPTICS MODULE TEMP.]
*1
Displays the status of the internal temperature of the projector.
[EXHAUST AIR TEMP.]
*1
Displays the status of the exhaust air temperature of the projector.
[AROUND LIGHT1 TEMP.]
*1
Displays the status of the temperature around light source 1 of the projector.
[AROUND LIGHT2 TEMP.]
*1
Displays the status of the temperature around light source 2 of the projector.
[COOLING CONDITION] Displays the set cooling conditions. Automatically recognized result is displayed when set to [AUTO].
[ATMOSPHERIC PRESSURE] Displays the atmospheric pressure.
[SELF TEST] Displays the status of the projector.
[INPUT] Displays the input terminal currently selected.
[BACKUP INPUT STATUS]
Displays whether switching to the backup input signal is possible or not when [BACKUP INPUT
MODE] is set to [OFF]. (x page 110)
[SIGNAL NAME] Displays the input signal name.
[SIGNAL FREQUENCY] Displays the frequency of the input signal.
[NUMBER OF REGISTERED
SIGNAL]
Displays the number of registered signals.
[REMOTE2 STATUS] Displays the control status of the REMOTE2.
[AC VOLTAGE] Displays the input supply voltage.
[UPGRADE]
[ET-UK20]
Displays the activation status by the Upgrade Kit (Model No.:
ET-UK20).
[ET-CUK10]
Displays the activation status by the Auto Screen Adjustment
Upgrade Kit (Model No.: ET-CUK10).
[ON COUNT]
[POWER ON TIMES] Displays the number of times the power is turned on.
[SHUTTER]
Displays the number of times the mechanical shutter is closed.
It is counted when [MECHANICAL SHUTTER] is set to [ENABLE].
[SIGNAL INFORMATION]
[MEMORY NO.] Displays the memory number of the input signal.
[INPUT] Displays the input terminal currently selected.
[SIGNAL NAME] Displays the input signal name.
[SIGNAL FREQUENCY] Displays the frequency of the input signal.
[SYNC.STATE] Displays the synch polarity of the input signal.
[V.SYNC WIDTH] Displays the vertical sync signal pulse width of the input signal.
[SCAN TYPE] Displays the scan type of the input signal.
[TOTAL DOTS] Displays the total dot count of the input signal.
[DISPLAY DOTS] Displays the number of input signal display dots.
[TOTAL LINES] Displays the total line count of the input signal.
[DISPLAY LINES] Displays the number of input signal display lines.
[SAMPLING] Displays the sampling information of the input signal.
[SIGNAL LEVEL] Displays the signal level of the input signal.
[BIT DEPTH] Displays the gradation of the input signal.
*1 The temperature status is indicated with text color (green/yellow/red) and bar scale. Use the projector within the range that the indication is
green.
Note
f Press the <ENTER> button while displaying the [STATUS] screen to send an E-mail including the content of status to the E-mail addresses
(up to two addresses) set in “[E-mail set up] page” (x page 172).
f Some items in [SIGNAL INFORMATION] may be displayed and others not displayed, depending on the signal being input.
f If any abnormality has occurred on the projector, press the <DEFAULT> button while the [STATUS] screen is displayed to display the detail
screen of the error information.
f For details on the contents displayed in [SELF TEST], refer to “Self-diagnosis display” (x page 189).
[AC VOLTAGE MONITOR]
Enable or disable the AC voltage monitor function. The value of input supply voltage is displayed on the self-
diagnosis display at the side of the projector when enabled.
1) Press as to select [AC VOLTAGE MONITOR].
