Operation Manual

Chapter 4 Settings — [PROJECTOR SETUP] menu
ENGLISH - 141
3) Press the <ENTER> button.
f The conrmation screen is displayed.
4) Press qw to select [OK], and press the <ENTER> button.
f To cancel, select [CANCEL].
f The lens moves up, down, left, and right to detect the lens shift limit value, and automatically set the home
position and the ET-D75LE90 lens standard position.
f The lens stops to complete the calibration.
Note
f [PROGRESS] is displayed in the menu during lens calibration. The operation cannot be canceled during calibration.
f When lens calibration executes correctly, [COMPLETE] is displayed and [INCOMPLETE] is displayed when it does not execute correctly.
f Pressing the <FOCUS> button on the remote control for at least three seconds will also display the conrmation screen for lens calibration
execution.
[LENS MEMORY]
Save and load the focus position, shift position, and zoom position of an adjusted lens.
Saving lens position
1) Press as to select [LENS MEMORY].
2) Press the <ENTER> button.
3) Press as to select [LENS MEMORY SAVE].
4) Press the <ENTER> button.
f The [LENS MEMORY SAVE] screen is displayed.
5) Press as to select the item to save, and press the <ENTER> button.
6) When the confirmation screen is displayed, press qw to select [OK], and press the <ENTER> button.
f The [LENS MEMORY NAME INPUT] screen is displayed.
7) Press asqw to select the text, and press the <ENTER> button to enter the text.
8) After the name is input, press asqw to select [OK], and press the <ENTER> button.
f The registration completes and returns to the [LENS MEMORY SAVE] screen.
f If you press asqw to select [CANCEL] and then press the <ENTER> button, the lens memory will not be
saved.
f If you press asqw to select [DEFAULT] and press the <ENTER> button, the entered name will not be
registered and the default name will be used.
f If you select [OK] without entering any characters and press the <ENTER> button, the default name will be
used.
Loading the lens position
1) Press as to select [LENS MEMORY].
2) Press the <ENTER> button.
3) Press as to select [LENS MEMORY LOAD].
4) Press the <ENTER> button.
f The [LENS MEMORY LOAD] screen is displayed.
5) Press as to select the item to load, and press the <ENTER> button.
6) When the confirmation screen is displayed, press qw to select [OK], and press the <ENTER> button.
f The lens moves automatically to the registered shift, zoom, and focus positions.
Note
f Lens memory is not guaranteed to be 100 % reproduced.
