Operation Manual

Chapter 4 Settings — [PROJECTOR SETUP] menu
140 - ENGLISH
[OFF] Does not return the response when an ID is designated as GROUP.
Note
f When [INPUT SELECT] is set to [DIGITAL LINK], communication using that serial terminal is available only when the corresponding device
(such as the optional DIGITAL LINK output supported device (Model No.: ET-YFB100G, ET-YFB200G)) is connected to the <DIGITAL LINK/
LAN> terminal.
f When transferring logos via the optional DIGITAL LINK output supported device (Model No.: ET-YFB100G, ET-YFB200G), setting for “NO
SIGNAL SLEEP” of the DIGITAL LINK output supported device should be set to “OFF” to avoid interruption of communication.
f When [INPUT SELECT] is set to [DIGITAL LINK], communication speed for input is xed to 9 600 bps and the parity is xed to “NONE”.
[REMOTE2 MODE]
You can set the <REMOTE 2 IN> terminal.
1) Press as to select [REMOTE2 MODE].
2) Press qw to switch the item.
f The items will switch each time you press the button.
[DEFAULT]
Uses pin assignment of the <REMOTE 2 IN> terminal in standard setting. (x page 203)
[USER] Changes the setting of the <REMOTE 2 IN> terminal.
f When [USER] is selected, proceed to Step 3).
3) Press the <ENTER> button.
4) Press as to select one from [PIN2] to [PIN8], and press qw to switch the setting.
[FUNCTION BUTTON]
Set the function of the <FUNCTION> button on the remote control.
1) Press as to select [FUNCTION BUTTON].
2) Press the <ENTER> button.
f The [FUNCTION BUTTON] screen is displayed.
3) Press as to select a function.
[DISABLE] Disables the <FUNCTION> button.
[P IN P]
Switches the [P IN P] setting ([OFF], [USER1], [USER2], or [USER3]). (x page 146)
[SUB MEMORY]
Displays the sub memory list. (x page 151)
[SYSTEM SELECTOR]
Switches the [SYSTEM SELECTOR] setting. (x page 88)
[SYSTEM DAYLIGHT VIEW]
Switches the [SYSTEM DAYLIGHT VIEW] setting. (x page 86)
[FREEZE]
Temporarily pauses the image. (x page 123)
[WAVEFORM MONITOR]
Displays the waveform of the input signal. (x page 123)
[LENS MEMORY LOAD]
Loads the registered lens memory. (x page 141)
[LEFT/RIGHT SWAP]
Switches the [LEFT/RIGHT SWAP] setting. (x page 103)
[PROJECTION METHOD]
Switches the [PROJECTION METHOD] setting. (x page 125)
4) Press the <ENTER> button.
[LENS CALIBRATION]
Detect the lens shift limit value of the projector and set the home position and the ET-D75LE90 lens standard
position automatically.
1) Press as to select [LENS CALIBRATION].
2) Press qw to switch the item.
f The items will switch each time you press the button.
[NORMAL]
Select this item when anything other than the Fixed-focus Lens (Model No.: ET-D75LE90) is used.
Move the lens to the home position after completing the calibration.
[D75LE90]
Select this item when the Fixed-focus Lens (Model No.: ET-D75LE90) is used.
Move the lens to the ET-D75LE90 lens standard position after completing the calibration.
