Operation Manual

Chapter 4 Settings — [PROJECTOR SETUP] menu
ENGLISH - 135
Note
f The power indicator <ON (G)/STANDBY (R)> will blink slowly in green while the no signal lights-out function is operating and the light source
is turned off.
f When [NO SIGNAL LIGHTS-OUT] is set to anything other than [DISABLE], the following are the conditions to turn the light source back on
again from the condition that the light source has turned off by this function.
g When the signal is input
g When on-screen display such as menu screen (OSD) or input guide, a test pattern, or a warning message is displayed
g When the power on <b> button is pressed
g When the operation to disable the shutter function (shutter: open) is performed, such as pressing the <SHUTTER> button
g When the operating environment temperature is around 0 °C (32 °F) and the light source is forced to turn on due to warm-up
[INITIAL STARTUP]
Set the startup method when the <MAIN POWER> switch is set to <ON>.
1) Press as to select [INITIAL STARTUP].
2) Press qw to switch the item.
f The items will switch each time you press the button.
[LAST MEMORY] Starts up the projector in the condition before the <MAIN POWER> switch is set to <OFF>.
[STANDBY] Starts up the projector in standby.
[ON] Starts projecting immediately.
[STARTUP INPUT SELECT]
Set the input when the projector is switched on to start projection.
1) Press as to select [STARTUP INPUT SELECT].
2) Press the <ENTER> button.
f The [STARTUP INPUT SELECT] screen is displayed.
3) Press asqw to select the input, and press the <ENTER> button.
[LAST USED] Keeps the input selected last.
[RGB1] Sets the input to RGB1.
[RGB2] Sets the input to RGB2.
[DVI-D] Sets the input to DVI-D.
[HDMI] Sets the input to HDMI.
[DIGITAL LINK] Sets the input to DIGITAL LINK.
[SDI1] Sets the input to SDI1.
[SDI2] Sets the input to SDI2.
[INPUT1] - [INPUT10]
*1
Sets the input to DIGITAL LINK, and switches the input of the Panasonic twisted-pair-cable
transmitter to the specied input.
*1 When the optional DIGITAL LINK output supported device (Model No.: ET-YFB100G, ET-YFB200G) is connected to the projector, its input
name is automatically reected from [INPUT1] to [INPUT10]. When an item that does not reect the input name is selected, it will be disabled.
Note
f If [BACKUP INPUT MODE] in the [DISPLAY OPTION] menu → [BACKUP INPUT SETTING] (x page 110) is set to [1], and the power is
turned off with the input set to HDMI in the previous use, the projection will start with DVI-D input even when [STARTUP INPUT SELECT] is
set to [LAST USED].
f When [BACKUP INPUT MODE] is set to [2] using the [DISPLAY OPTION] menu → [BACKUP INPUT SETTING] (x page 110), and the
power is turned off with the input set to SDI2 in the pervious use, projection will start with the SDI1 input even if [STARTUP INPUT SELECT]
is set to [LAST USED].
[DATE AND TIME]
Set the time zone, date, and time of the built-in clock of the projector.
Setting the time zone
1) Press as to select [DATE AND TIME].
2) Press the <ENTER> button.
f The [DATE AND TIME] screen is displayed.
