12) Adjust [LIGHT OUTPUT] of each projector.
f Adjust [LIGHT OUTPUT] of all the other projectors so that the brightness will be the same as the projector
with the least brightness.
13) Set [CONSTANT MODE] of [BRIGHTNESS CONTROL SETUP] to [AUTO], and [LINK] to [GROUP A] in
all projectors.
14) Select [APPLY] of [BRIGHTNESS CONTROL SETUP] and press the <ENTER> button in all projectors.
f Brightness control starts.
Note
f Brightness is automatically corrected whenever the light source lights up by switching on/off the projector, etc.
f When the variation in brightness has increased due to aging of the light source, or when you replaced the light source, readjust the
brightness control.
[STANDBY MODE]
Set the power consumption during the standby.
1) Press as to select [STANDBY MODE].
2) Press qw to switch the item.
f The items will switch each time you press the button.
[NORMAL] Select this item to use the network function during standby.
[ECO] Select this item to reduce power consumption during standby.
Note
f The AC voltage monitor function, the network function, the <SERIAL OUT> terminal, and part of the RS-232C command cannot be used
during the standby when set to [ECO].
When an error or warning occurs on the projector, the self-diagnosis display appears on the control panel regardless of the [STANDBY
MODE] settings. (x page 189)
f When [ECO] is set, it may take approximately 10 seconds longer before the projector starts projecting after the power is turned on,
compared with when [NORMAL] is set.
f When [NORMAL] is set, the network function and the <SERIAL OUT> terminal can be used during standby.
f The [STANDBY MODE] setting will not reset to the factory default even if [ALL USER DATA] is executed from the [PROJECTOR SETUP]
menu → [INITIALIZE].
[NO SIGNAL SHUT-OFF]
A function that automatically switches the power source of the projector to standby if there is no input signal for a
certain period of time. The time before switching to standby can be set.
1) Press as to select [NO SIGNAL SHUT-OFF].
2) Press qw to switch the item.
f The items will switch each time you press the button.
[DISABLE] Disables the No signal shut-off function.
[10MIN.] - [90MIN.] Sets the time in increments of 10 minutes.
[NO SIGNAL LIGHTS-OUT]
This is a function to automatically turn off the light source of the projector when there is no input signal for specic
period. The time until the light source is turned off can be set.
1) Press as to select [NO SIGNAL LIGHTS-OUT].
2) Press qw to switch the item.
f The items will switch each time you press the button.
[DISABLE] Disables the no signal lights-out function.
[10SEC.] - [5MIN.]
Turns off the light source when there is no input signal for the preset period.
Select [10SEC.], [20SEC.], [30SEC.], [1MIN.], [2MIN.], [3MIN.], or [5MIN.].
