Chapter 4 Settings — [PROJECTOR SETUP] menu
132 - ENGLISH
[BRIGHTNESS CONTROL STATUS] screen display example
When [CONSTANT MODE] of [BRIGHTNESS CONTROL SETUP] is set to [OFF]
The screen shows the status that the brightness control is disabled.
1
RETURN
BRIGHTNESS CONTROL STATUS
CONSTANT MODE
PROJECTOR
OFF
MENU
When [CONSTANT MODE] of [BRIGHTNESS CONTROL SETUP] is set to [AUTO] and [LINK] is set to [OFF]
The screen shows the status of the brightness control in one projector.
5
1
6
RETURN
LINK
PROJECTOR
OFF
BRIGHTNESS CONTROL STATUS
MENU
When [CONSTANT MODE] of [BRIGHTNESS CONTROL SETUP] is set to [AUTO] and [LINK] is set from
[GROUP A] to [GROUP D]
The screen shows the status of the brightness control of synchronized projectors (up to eight units), including the
projector being controlled through the on-screen menu.
2
1
3
4
5
7
8
1:
2:
3:
4:
5:
6:
7:
192. 168. 30. 2
192. 168. 30. 3
192. 168. 30. 4
LINK
UPDATE
PROJECTOR
GROUP A
PROJECTOR2
PROJECTOR3
BRIGHTNESS CONTROL STATUS
MENU SELECT
When [CONSTANT MODE] of [BRIGHTNESS CONTROL SETUP] is set to [PC]
5
1
6
RETURN
CONSTANT MODE
PROJECTOR
PC
BRIGHTNESS CONTROL STATUS
MENU
1 Display the name of the projector.
2 Display the synchronized group.
3 Display the IP address of the projector.
4 Display the names and IP addresses of projectors in same group detected over the network.
