Operation Manual

Chapter 4 Settings — [DISPLAY OPTION] menu
ENGLISH - 121
[UNIFORMITY]
Correct the brightness and color unevenness of the entire screen.
Setting each color
1) Press as to select [UNIFORMITY].
2) Press the <ENTER> button.
f The [UNIFORMITY] screen is displayed.
3) Press as to select [WHITE], [RED], [GREEN], or [BLUE].
4) Press qw to adjust the level.
Item Operation Adjustment Range of adjustment
[VERTICAL]
Press w.
The lower-side color becomes
pale, or the upper-side color
becomes dark.
- 127 - +127
Press q.
The upper-side color becomes
pale, or the lower-side color
becomes dark.
[HORIZONTAL]
Press w.
The left-side color becomes pale,
or the right-side color becomes
dark.
Press q.
The right-side color becomes
pale, or the left-side color
becomes dark.
Setting [PC CORRECTION]
To use the [PC CORRECTION] function, the optional Upgrade Kit (Model No.: ET-UK20) is required. To purchase
the product, consult your dealer.
1) Press as to select [UNIFORMITY].
2) Press the <ENTER> button.
f The [UNIFORMITY] screen is displayed.
3) Press as to select [PC CORRECTION].
4) Press qw to switch the item.
[OFF] Does not perform correction using a computer.
[ON]
*1
Performs correction for the brightness and color unevenness of the entire screen using a computer.
*1 Advanced skills are necessary to use computer control correction. Consult your dealer.
Note
f The [UNIFORMITY] setting value will not return to factory default even if [ALL USER DATA] is executed from the [PROJECTOR SETUP]
menu → [INITIALIZE] (x page 144).
[SHUTTER SETTING]
Set the image fade-in and fade-out when the shutter function operates. You can also congure the setting to
automatically enable/disable the shutter (shutter: close/open) when the power is turned off/on, and to use the
mechanical shutter or not.
Setting [MECHANICAL SHUTTER]
1) Press as to select [SHUTTER SETTING].
2) Press the <ENTER> button.
f The [SHUTTER SETTING] screen is displayed.
3) Press as to select [MECHANICAL SHUTTER].
