Operation Manual

Chapter 4 Settings — [DISPLAY OPTION] menu
110 - ENGLISH
2) Press the <ENTER> button.
f The [AUTO SETUP] screen is displayed.
3) Press as to select [POSITION ADJUST].
4) Press qw to switch the item.
[ON] Adjust the screen position and size when automatic setup is executed.
[OFF] Does not perform automatic adjustment.
Adjusting signal level automatically
1) Press as to select [AUTO SETUP].
2) Press the <ENTER> button.
f The [AUTO SETUP] screen is displayed.
3) Press as to select [SIGNAL LEVEL ADJUST].
4) Press qw to switch the item.
[OFF] Does not perform automatic adjustment.
[ON]
Adjusts black level (on-screen menu [BRIGHTNESS]) and white level (on-screen menu
[CONTRAST]) when automatic setup is executed.
Note
f [SIGNAL LEVEL ADJUST] may not function properly unless a still image containing clear blacks and whites is input.
[BACKUP INPUT SETTING]
Set the backup function that switches the signal to the backup input signal as seamless as possible when input
signal is disrupted.
1) Press as to select [BACKUP INPUT SETTING].
2) Press the <ENTER> button.
f The [BACKUP INPUT SETTING] screen is displayed.
3) Press as to select [BACKUP INPUT MODE].
4) Press qw to switch the item.
f The items will switch each time you press the button.
[OFF] Disables the backup function.
[1]
Enables the backup function between the DVI-D input and the HDMI input.
The input is switched as seamless as possible when the same signal is input to the primary and
secondary inputs.
Primary input is xed to the <DVI-D IN> terminal, and the secondary input is xed to the <HDMI IN>
terminal.
[2]
Enables the backup function between the SDI1 input and the SDI2 input.
The input is switched as seamless as possible when the same signal is input to the primary and
secondary inputs.
Primary input is xed to the <SDI IN 1> terminal, and the secondary input is xed to the <SDI IN 2>
terminal.
5) Press as to select [AUTOMATIC SWITCHING].
f When [BACKUP INPUT MODE] is set to [OFF], [AUTOMATIC SWITCHING] cannot be selected.
6) Press qw to switch the item.
f The items will switch each time you press the button.
[ENABLE] Switches to the secondary input automatically when the input signal for primary input is disrupted.
[DISABLE] Disables the automatic input switching function.
