Operation Manual

Chapter 4 Settings — [3D SETTINGS] menu
ENGLISH - 105
Note
f This function is disabled when [3D SYSTEM SETTING] is set to anything other than [SINGLE].
f The crosstalk may get larger or the displayed image may get darker when the setting does not match with the 3D system in use.
[3D FRAME DELAY]
Adjust the timing of the left-right switch of an image.
1) Press as to select [3D FRAME DELAY].
2) Press qw to switch the item.
[0us] - [25000us] Sets the amount in 10 us increments.
f The adjustment range depends on the input signal.
[3D TEST MODE]
Set the image display mode for use with 3D system adjustments.
1) Press as to select [3D TEST MODE].
2) Press qw to switch the item.
[NORMAL] Normal setting.
[LEFT/LEFT] Displays the image of the left eye input signal for both the left and right eye image.
[RIGHT/RIGHT] Displays the image of the right eye input signal for both the left and right eye images.
[LEFT/BLACK]
Displays the image of the left eye input signal for the left eye image, and all black images for the right
eye image.
[BLACK/RIGHT]
Displays all black images for the left eye image, and the image of the right eye input signal for the
right eye image.
Note
f The [3D TEST MODE] setting returns to [NORMAL] when the projector is switched off.
f This function is disabled when [3D SYSTEM SETTING] is set to anything other than [SINGLE].
f This function is disabled when [3D TEST PATTERN] is displayed.
[3D TEST PATTERN]
The 3D test pattern can be used to check operation and make adjustments even without a 3D signal.
1) Press as to select [3D TEST PATTERN].
2) Press qw to switch the item.
Menu screen + input screen
Select a test pattern that is easy to check operation or make adjustment.
Menu screen + left: white/
right: black
Menu screen + left: black/
right: white
Note
f When the [DISPLAY OPTION] menu → [RGB IN] → [RGB1 INPUT SETTING] (x page 112) is set to [VIDEO] or [Y/C], the 3D test pattern
cannot be displayed while the <RGB 1 IN> terminal is selected.
f This function is disabled when [3D SYSTEM SETTING] is set to anything other than [SINGLE].
