Owner manual

Indoor Unit : XS1872 & PNR-XS1872
Outdoor Unit : CL1872
Power Supply : 230V Single Phase 60Hz
< Cooling Capacity (Low Ambient) >
TC : Total Cooling Capacity (BTU/h) SHC : Sensible Heat Capacity (BTU/h)
1.
2. Above data represents the value when the operation frequency of a compressor is fixed.
Above data does not take Freeze Prevention Protection during cooling operation into account.
For this reason, the value may vary from the actual cooling characteristics.
NOTE
RATING CAPACITY: 17,500 BTU/h AIR FLOW RATE: 341 CFM
INDOOR OUTDOOR
ENT. TEMP.
o
F (
o
C) AMBIENT TEMP.
o
F (
o
C)
W.B. D.B. 0 5 15 25 35 45 55
(-17.8) (-15.0) (-9.4) (-3.9) (1.7) (7.2) (12.8)
TC 14,930 14,970 14,980 14,970 15,000 15,040 15,030
CI
0.87 0.91 0.94 0.81 0.79 0.78 0.82
72 (22.2) SHC 10,530 10,530 10,600 10,530 10,600 10,600 10,600
59 76 (24.4) SHC 11,720 11,790 11,790 11,790 11,790 11,790 11,790
(15.0) 80 (26.7) SHC 12,980 12,980 12,980 12,980 13,050 13,050 13,050
84 (28.9) SHC 14,180 14,180 14,240 14,180 14,240 14,240 14,240
88 (31.1) SHC 14,930 14,970 14,980 14,970 15,000 15,040 15,030
TC 14,710 14,770 14,840 14,940 15,030 15,130 15,180
CI 0.98 1.02 1.03 0.87 0.85 0.82 0.85
72 (22.2) SHC 8,610 8,680 8,680 8,740 8,810 8,810 8,870
63 76 (24.4) SHC 9,800 9,870 9,870 9,930 10,000 10,070 10,070
(17.2) 80 (26.7) SHC 11,060 11,130 11,130 11,190 11,260 11,260 11,330
84 (28.9) SHC 12,260 12,320 12,320 12,390 12,450 12,450 12,520
88 (31.1) SHC 13,450 13,510 13,510 13,580 13,650 13,710 13,710
TC 14,330 14,410 14,560 14,780 14,960 15,130 15,250
CI 1.11 1.14 1.14 0.95 0.91 0.86 0.88
72 (22.2) SHC 6,690 6,750 6,820 6,890 6,950 7,080 7,080
67 76 (24.4) SHC 7,880 7,950 8,010 8,080 8,140 8,280 8,280
(19.4) 80 (26.7) SHC 9,140 9,210 9,270 9,340 9,400 9,540 9,540
84 (28.9) SHC 10,330 10,400 10,470 10,530 10,600 10,730 10,730
88 (31.1) SHC 11,530 11,590 11,660 11,720 11,860 11,920 11,990
TC 13,770 13,880 14,110 14,480 14,750 15,010 15,200
CI 1.25 1.28 1.27 1.04 0.97 0.91 0.91
72 (22.2) SHC 4,700 4,760 4,830 4,960 5,100 5,160 5,230
71 76 (24.4) SHC 5,890 5,960 6,020 6,160 6,290 6,360 6,490
(21.7) 80 (26.7) SHC 7,150 7,220 7,280 7,420 7,550 7,610 7,680
84 (28.9) SHC 8,340 8,410 8,480 8,610 8,740 8,810 8,940
88 (31.1) SHC 9,540 9,600 9,670 9,800 9,930 10,000 10,130
TC 13,080 13,210 13,540 14,070 14,440 14,790 15,060
CI 1.38 1.42 1.39 1.13 1.04 0.96 0.95
75 76 (24.4) SHC 4,030 4,030 4,170 4,370 4,500 4,630 4,700
(23.9) 80 (26.7) SHC 5,290 5,290 5,430 5,630 5,760 5,890 5,960
84 (28.9) SHC 6,490 6,490 6,620 6,820 6,950 7,080 7,150
88 (31.1) SHC 7,680 7,680 7,810 8,010 8,140 8,280 8,340
