Product Manual
u1fmdl1sm-rev0316 Model U1F UL79 Listed Metallic Design Level 1 Page 11
Composite Repair Parts List
ITEM PART NUMBER DESCRIPTION QTY
1 031-183-000 Air Valve Assembly 1
2 050-028-760 Ball, Check 4
050-028-600 Ball, Check 4
3 070-012-170 Bushing 2
4 095-110-000 Pilot Valve Assembly 1
5 114-025-157 Intermediate 1
6 132-019-360 Bumper 2
7 135-036-506 Bushing 2
8 165-120-157 Cap, Air Inlet Assembly 1
9 170-044-330 Capscrew, Hex Hd 5/16-18 X 1.00 16
10 170-045-330 Capscrew, Hex Hd 5/16-18 X 1.25 16
11 170-069-330 Capscrew, Hex Hd 5/16-18 X 1.75 4
12 170-006-330 Capscrew, Hex Hd 3/8-16 X 1.00 4
13 196-173-156 Chamber, Outer 2
14 286-008-760 Diaphragm 2
286-008-365 Diaphragm 2
15 286-015-604 Diaphragm, Overlay 2
16 360-093-360 Gasket, Air Valve 1
ITEM PART NUMBER DESCRIPTION QTY
17 360-103-360 Gasket, Pilot Valve 1
18 360-104-379 Gasket, Air Inlet 1
19 518-175-156 Manifold, Suction 1
518-175-156E Manifold, Suction 1" BSP Tapered 1
20 518-176-156 Manifold, Discharge 1
518-176-156E Manifold, Discharge 1" BSP Tapered 1
21 560-001-379 O-Ring 2
22 560-091-611 O-Ring (used with seat #722.098.150) 8
23 612-022-330 Plate, Inner Diaphragm 2
24 612-108-157 Plate, Outer Diaphragm Assembly 2
25 620-022-115 Pin, Actuator 2
26 675-042-115 Ring, Retaining 2
27 685-060-120 Rod, Diaphragm 1
28 720-010-375 Seal, U-Cup 2
29 722-098-600 Seat, Check Ball 4
722.098.150 Seat, Check Ball 4
30 900-004-330 Lockwasher 16
31 901-038-330 Flatwasher 4
32 920-025-000 Ground Strap 1
33 530-033-000 Metal Mufer 1
