Quick Guide
7 - English
1. Install the bracket using the template
The Anti-Tip bracket is packaged with a template. The instructions include information necessary to complete the installation. Read and follow
the instructions on the sheet (template) for range installation.
2. Level the range
Leveling leg
Raise
range
Lower range
Level the range by adjusting the leveling legs with a wrench.
3. Check your adjustments
Use a spirit level to check your adjustments. Place the level diagonally on the oven rack or
surface cooktop, and conrm the range is level in the two directions shown below.
A. Check direction A.
B. Check direction B.
If the spirit level indicates that the range is not level, adjust the leveling legs with a
wrench.
Ground
CAUTION
For your safety, do not attempt to modify or straighten front legs. Front leveling legs on the range are
designed to be slanted to prevent accidental tipping.
Finalizing the installation
Anti-Tip
bracket
Leveling leg
• Move range close enough to the opening to plug into the
receptacle.
• Slide the range into position ensuring that the rear left (or rear
right) leg slides under the Anti-Tip bracket.
• Carefully tip the range forward to insure that the Anti-Tip bracket
engages the back brace and prevents tip-over.
• Turn on the electrical power. Check the range for proper operation
as described in the user manual.
