9
ENG
● DESCRIPTION
11
S.DIRECT BUTTON
Used to select the S.DIRECT mode.
(Output the original signal as it is without applying the sound fi eld effect or any other sound effect.
12
MASTER VOLUME CONTROL
Adjusts the volume level.
13
POWER
Turns the receiver on/off.
14
PHONE JACK
Used to connect a set of headphones.
15
AUX IN JACKS
Auxiliary AV input terminals used to connect a camcorder, portable DVD player or gaming device.
16
ASC MIC JACK
Used to connect the ASC MIC for setting up ASC (Auto Sound Calibration).
17
UP(,), DOWN(.), LEFT(<),
RIGHT(>) BUTTONS
Used to move the cursor up, down, left or right.
Also used to select detailed options in the
AUDIO EFFECT mode and to change the tone level.
18
MULTI CH BUTTON
Used to select a connected 7.1 multi channel player.
19
AV SYNC BUTTON
Used to select the Audio Delay Mode.
20
TUNING MODE BUTTON
Used to select the Manual or Preset mode for FM radio.
21
SELECT BUTTON
Used to change the radio frequency.
22
TUNER MEMORY BUTTON
Used to set a preset radio frequency.
