BASIC FUNCTIONS OF YOUR AV RECEIVER
AUDIO SETUP
Selecting a source device and connection jack (Digital Audio In)
Select the external devices you have connected to the receiver.
Press the SETUP/MENU button on the remote control.
Each time the button is pressed, the mode switches between
SETUP ENTER and SETUP OFF.
Press the ENTER button to select SETUP ENTER.
Press the
▲▼
buttons to select AUDIO SETUP, and then press the
ENTER or ► button.
Press the
▲▼ buttons
to select a desired jack.
Devices switch as follows; BD/DVD, SAT, TV, CD
- To exit setup mode -
Press the SETUP/MENU button on the remote control.
SETUP OFF appears on the display and Setup Mode is exited.
You can also use the SETUP, ,,.,
<
,
>
, ENTER buttons on the front of your AV Receiver.
1.
•
2.
3.
4.
•
•
M
Æ
Æ
1 2
3 4 5
In ZONE2 FM mode, you can switch only between the preset channels that you have specifi ed in the main zone.
ZONE2 is enabled only for an analog input source; the digital source is not applicable. If you still encounter a failure after
following all these instructions, check if the input source is of the analog type. You cannot listen to one FM program in the
main zone and a different program in the sub zone.
You can use MUTE on the remote control to mute the output sound of ZONE2.
Main Zone : Off, Zone 2 : On
It is possible to change into the state of "Main Zone : On, Zone 2 : On" from the state of
"Main Zone : Off, Zone 2 : On" .
M
1
MULTI ZONE
4
Tuner Preset Mode
2
Indicator
5
Volume Control
3
Function
6
Tuner Preset Frequency
POWER
AMP/TV BD/DVD
INPUT SELECT
TV SOURCE
123
MAIN/
ZONE2
AMP
/
TV BD
/
DVD
1
2
3
TUNER
MEMORY
SUB WOOFER MO/ST
MUTE
ASC
VOL
TUNING
/ CH
TUNER
MEMOR
Y
S
UB WOOFER
M
O/
ST
AS
C
iPod
TV/AUX1
BD/DVD
SAT
MULTI CH VCR/AUX2
CD
iP
o
d
M
ULTI CH
6
