MX-HS9000 PREMIUM HI-FI Component System user manual imagine the possibilities Thank you for purchasing this Samsung product. To receive more complete service, please register your product at www.samsung.com/register This Nanum Gothic Eco font is provided by NAVER.
Safety Information Warning TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE THE COVER (OR BACK). NO USER-SERVICEABLE PARTS ARE INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. This symbol indicates “dangerous voltage” inside the product that presents a risk of electric shock or personal injury. CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.
FCC NOTES (for U.S.A) Important Safety Instructions Read these operating instructions carefully before using the unit. Follow all the safety instructions listed below. Keep these operating instructions handy for future reference. 1. Read these instructions. 2. Keep these Instructions. 3. Heed all warnings. 4. Follow all instructions. 5. Do not use this apparatus near water. 6. Clean only with dry cloth. 7. Do not block any ventilation openings.
Safety Information Precautions • Ensure that the AC power supply in your house complies with the identification sticker located on the back of your product. • Install your product horizontally, on a suitable base (furniture), with enough space around it for ventilation (3 - 4 inches/7.5 10 cm). • Do not place the product on amplifiers or other equipment which may become hot. Make sure the ventilation slots are not covered. • Do not stack anything on top of the product.
Disc and Format Compatibility Supported Audio Formats File Extension CD-R Discs • Some CD-R discs may not be playable depending on the disc recording device (CDRecorder or PC) and the condition of the disc. • Use 650MB/74 minute CD-R discs. Do not use CD-R discs over 700MB/80 minutes as they may not be played back. • Some CD-RW (Rewritable) media may not be playable. • Only CD-Rs that are properly "closed" can be fully played.
Contents 16 Safety Information 2 4 4 5 5 17 Warning Precautions 17 Disc Storage & Management 17 18 Disc and Format Compatibility Supported Audio Formats 18 Getting Started 7 8 9 10 10 10 10 18 Front Panel Rear Panel 18 Remote Control 19 Accessories 19 Connecting the Speakers Cautions on Moving the Speakers Attaching the Speaker foot Functions 11 The Display function 11 11 12 12 Loading a Compact Disc CD/MP3/CD-R Playback Selecting a Track Searching for a Specific Music Passage on a CD
Getting Started Front Panel 1 43 2 5 6 k l m h 7 8 9 g f e ad) ( % $#@ 0! ( MIC jack ) AUX IN 1 jack Use to connect an external device such as an MP3 player. • Connect AUX IN 1 on the front panel of the product to the Audio Out of an external device/MP3 player. • Press the TUNER/AUX button to select AUX1. a USB REC button b +PANNING button c DJ BEAT button d TEMPO button VOLUME/SEARCH JOG e USB 2 jack for Playing and USB Recording @ ENTER button f USB 1 jack for Playback only.
Getting Started Rear Panel 1 23 4 5 6 FM Antenna Terminals 1 2 7 4 1. Connect the FM antenna to the FM antenna connector terminal. 2. Slowly move the antenna wire until you find a location where reception is good, then fasten it to a wall or other rigid surface. 3. If reception is poor, you may need to install an outdoor antenna. To do so, connect an outdoor FM antenna to the FM socket on the rear of the system using a 75Ω coaxial cable (not supplied). 2.
Remote Control Power BEAT WAVING Bluetooth CD TV SoundConnect USB REC REC SPEED USB TUNING MODE TUNER/AUX MO/ST +PANNING DJ BEAT NON-STOP MUSIC RELAY EFFECT LEVEL TEMPO SKIP SEARCH PLAY/PAUSE STOP REPEAT GIGA SOUND BEAT GOAL FOOTBALL EQ DANCE TIME TUNING/ALBUM ,,. VOLUME (–, +) PROGRAM DELETE SLEEP (Set a sleep time to shut off the product.
Getting Started Accessories Check for the supplied accessories below. User Manual (AH68-02687A) Remote Control / Batteries (AH59-02613A/4301-000116) Power Cable (3903-000467) FM Antenna (AH42-00021A) Rubber Foot (4ea) (AH81-05916L) • Figures and illustrations in this user's manual are provided for reference only and may differ from actual product appearance. Connecting the Speakers Cautions on Moving the Speakers Recommended speaker setup.
Functions The Display function Playing a CD Changing Display mode Press the DISPLAY/DEMO button on the product. Each time you press this button, the mode will change as follows: • The Dimmer function The Dimmer function is selected and the display darkens. • LED OFF The Front display LED is turned off while the dimmer function is working. • Clock ON The Clock you set is displayed. • Display/LED ON All displays and the LED are turned on.
Functions 3. To adjust the volume: • Turn the VOLUME control on the product. Selecting a Track ress the VOL+ or VOL- button on the • P remote control. The volume level can be adjusted in 31 steps (VOLUME MIN, VOLUME 01 ~ VOLUME 29, and VOLUME MAX). 4. 5. PAUSING PLAYBACK Main Unit To pause playback temporarily, press the button. again to continue playing the Press disc. Remote control To pause playback temporarily, press the button. button to continue playing Press the the disc.
2. • TRACK : Repeatedly plays the selected track. • DIR (DIRECTORY) : Repeatedly plays all tracks in the selected folder. • ALL : Repeatedly plays the entire disc. • RANDOM : Plays tracks in random order. Playing USB Devices Connect an external storage device such as a USB flash memory or external HDD (Hard Disk Drive) to the product. You can play files in MP3/WMA format. To Select a File from a USB Device You can select an MP3 file while the product is playing.
Functions To Use High Speed Search You can search a desired section quickly while the product is playing. Press the 3, 4 button. • Each time you press the button, you move through the section forward/backward quickly. ||IMPORTANT | ✎✎ The product does not output sound during a high speed search. ✎✎ You can also press and hold the 1 or 2 button on the main unit to automatically scan for a track. To Delete a File You can delete a file from your USB device. 1. Select a file you want to delete. 2.
You can select a track directly without the 1, 2 button. CDDA/MP3-CD/USB 1. 2. Press the SEARCH button. After pressing the SEARCH button, turn the VOLUME/SEARCH JOG control on the product to the left or right to select a desired track. • You can move to the selected track directly. When searching is done, the track will automatically start playing. ||NOTEs | ✎✎ CD/USB program play will continue if you try to switch to another mode.
Functions Bluetooth You can use a Bluetooth device to enjoy music with high quality stereo sound, all without wires! What is Bluetooth? Bluetooth is a technology that enables Bluetooth compliant devices to interconnect easily with each other using a short, wireless connection. • A Bluetooth device may cause noise or malfunction, depending on usage, when: -- A part of your body is in contact with the receiving/transmitting system of the Bluetooth device or the Hi-Fi Component.
✎✎ Only one Bluetooth device can be paired at a time. ✎✎ The Hi-Fi Component system may not search or connect properly in the following cases: -- If there is a strong electrical field around the Hi-Fi Component. -- If several Bluetooth devices are simultaneously paired with Hi-Fi Component. -- If the Bluetooth device is turned off, not in place, or malfunctions.
Functions TV SoundConnect You can listen to the sound from your SoundConnect Compatible Samsung TV through the Hi-Fi Component by using the TV SoundConnect function. To connect the Hi-Fi Component to a SoundConnect Compatible Samsung TV Before activating this function, be sure to set the Samsung TV's SoundConnect or SoundShare function to On. 1. Press the TV SoundConnect button of the Hi-Fi Component to display the TV SOUNDCONNECT message. 2.
Using My Karaoke Auto Change Function 1. Connect the microphone to the MIC jack on the front of the product. • If your microphone plug is smaller than the 6.3mm MIC jack, you need a Connector-Adaptor (not supplied) to complete the connection. -- First, connect the Connector-Adaptor to the MIC jack on the front of the product, -- Second, connect the microphone (with larger jack) to the ConnectorAdaptor. 2. Press the MIC VOL-, + button on the remote control to adjust the volume of the microphone. 3.
Functions 3. 4. Find a station by: • Pressing and holding the TUNING/ ALBUM , or . button on the remote control to automatically search for broadcasting stations. Press the MO/ST button to switch between stereo and mono. • In a poor reception area, select MONO for a clear, interference-free broadcast. • This applies only when listening to an FM station. 5. If you do not want to store the radio station found, go back to Step 3 and search for another station.
Press the ¬ button. Result: ON TIME is displayed for a few seconds. You can set the timer switch-on time. 3. Set the timer switch-on time. 7. Press the ¬ button. Result: TIMER REC SET (Do you want to record?) is displayed. 8. Press the ¬ button. Result: REC SET YES/NO is displayed. You can press the TUNING/ALBUM , or . button to select REC YES or REC NO, and then press ¬ button. a. Press the TUNING/ALBUM , or . button to set the hours. b. Press the ¬ button. Result: The minutes flash.
Functions Cancelling the Timer USB 1 (Recording device is on USB 2) After you have set the timer, it will start automatically. When it starts, the TIMER ON message appears on the display. If you no longer want to use the timer, you must cancel it. • To cancel the timer, Press the TIMER ON/OFF button once. • To restart the timer, Press the TIMER ON/OFF button once again. • Connect the USB device with the files you want to record to USB 1 jack.
• Press the USB REC button for a second to start FILE COPY. Press and hold the USB REC button for a few seconds to start FOLDER COPY. External Source • “AUX RECORD” is displayed and recording starts. ✎✎ When you use the CD high speed search function, the CD recording function is unavailable. ✎✎ With some USB devices, recording time may be longer. ✎✎ In the Program mode, you can't use the recording function.
Functions Special Sound Effects Selecting EQ Mode Your Hi-Fi Component system provides predefined equalizer settings that are optimized for particular music genre. You can also adjust the bass, middle, and treble levels manually. 1. Press the EQ button.
GIGA SOUND Function The GIGA SOUND function amplifies the bass sound and provides twice the bass for powerful, realistic sound. 1. Press the GIGA SOUND BEAT button on the main unit or the GIGA button on the remote control. Each time you press this button, the mode changes as follows: GIGA SOUND BEAT ; GIGA SOUND OFF 2. To cancel this function, press the GIGA SOUND BEAT button until “GIGA SOUND OFF” is displayed. ||NOTEs | ✎✎ The GIGA SOUND mode may be different depending on your region.
Functions +PANNING Funcion Increases the left and right speaker's output in turn and makes it seem as if the sound is moving from side to side. ||NOTEs | ✎✎ To apply the PANNING effect to another effect, press the +PANNING button when the other effect is active or press another effect button when the PANNING effect is active. NON-STOP MUSIC RELAY Function The NON-STOP MUSIC RELAY function plays music continuously without an interval between tracks/files.
Appendix Troubleshooting Symptom Check/Remedy I cannot eject the disc. • Is the power cord plugged securely into the outlet? • Turn off the power and then turn it back on. Playback does not start immediately when the Play/Pause button is pressed. • Are you using a deformed disc or a disc with scratches on the surface? • Wipe the disc clean. Sound is not produced. • No sound is heard during fast playback, slow playback, and step motion playback.
Appendix Specifications Power Requirements AC110-120V ~ 50/60Hz Power Consumption 146W Weight General FM Tuner CD Disc Amplifier Dimensions Main unit 17.6 Ibs Speaker 144.6 Ibs Main unit 23.2 (W) x 9.4 (H) x 15.3 (D) inches Speaker 23.2 (W) x 34.9 (H) x 21.6 (D) inches Operating Temperature Range 41°F~95°F (5°C~35°C) Operating Humidity Range 10 % to 75 % Signal/Noise ratio 55 dB Usable sensitivity 10 dB Total harmonic distortion 1% CD : 12 cm (COMPACT DISC) Reading Speed : 4.
LIMITED WARRANTY TO ORIGINAL PURCHASER This SAMSUNG brand product, as supplied and distributed by Samsung Electronics America, Inc.
QUESTIONS OR COMMENTS? Area IN THE US CALL 1-800-SAMSUNG (726-7864) OR VISIT US ONLINE AT WRITE www.samsung.com/us/ support Samsung Electronics America, Inc. 85 Challenger Road Ridgefield Park, NJ 07660 © 2014 Samsung Electronics Co., Ltd. All rights reserved.
