Introduction Congratulations on purchasing the Samson S curve 231 dual channel,1/3 Octave, 31 Band Constant Q Graphic Equalizer! Although this product is designed for easy operation, we suggest you take some time out first to go through these pages so you can fully understand how we’ve implemented a number of unique features. The S curve 231 is a professional quality signal processor that gives you precise tonal control over a stereo, or two mono audio signals.
S curve 231 Features The Samson S curve 231 Graphic Equalizer utilizes state-of-the-art, Constant Q filtering technology for precise tonal control. Here are some of it’s main features: • The S curve 231 is a two channel equalizer and each channel provides 31 bands of equalization, with each frequency band representing 1/3 of an octave in the 20 Hz to 20 kHz range.
Controls and Functions FRONT PANEL LAYOUT 1 Equalizer level sliders - Independent Equalizer sliders are provided for each frequency area (The S curve 231 provides 31 frequency areas).Calibration markings on either side of each Equalizer slider allow you to cut or boost each frequency area. As described below, the exact action of the Equalizer sliders depends upon the setting of the Range switch as well as the setting of the Cut Only switch (see #3 and #5).
Controls and Functions 5 CUT ONLY switch - When pressed in, the LED switch lights and all the Equalizer sliders serve to attenuate their frequency areas only (there is no boost) by up to 6 or 12 dB, depending upon the setting of the RANGE switch (see #7 below). The Cut Only switch should be used when you need to notch out certain frequencies in order to reduce feedback or “ring out” a room. See the “Using the S curve 231 to remove feedback” section in this manual (page 14) for more information.
SETTING UP THE S curve 231 SETTING UP THE S curve 231 Setting up your S curve 231 Graphic Equalizer is a simple procedure which takes only a few minutes: 1. Remove all packing materials (save them in case of need for future service) and decide where the unit is to be physically placed—it can be used free-standing or mounted in a standard 19" rack. 2. Make sure the power to all mixers and amplifiers in your audio system is off.
SETTING UP THE S curve 231 7. Press the front panel Power switch to turn on the S curve 231. Press the Equalizer switches in to activate the equalizer. Note that audio signal will be muted for approximately five seconds until the relay power-on circuitry is activated (at which time you’ll hear a click and the audio signal will be unmuted). 8. Apply an input signal to the S curve 231 (if sending signal from a mixer output bus, drive the mixer’s output meters at approximately 0 VU).
S curve 131 System Configurations Using the S curve 231 with Active Speakers In this example, the mixer’s stereo output is connected to the S curve 231’s inputs. Then, the S curve 231’s outputs are connected to the inputs of each active (self-powered) loudspeaker. Using the S curve 231 with Passive Speakers In this example the mixer’s stereo output is connected to the S curve 231’s inputs. Then, the S curve 231’s outputs are connected to the input of a 2-channel power amp.
S curve 131 System Configurations Using the S curve 231 in Insert Points You can use the S curve 231 in your mixer’s insert points if you want to equalize two mono channels individually in the mix. In this example the S curve 231’s Channel 1 INPUT and OUTPUT are inserted on a bass guitar channel using a 1/4-inch TRS to 2 x 1/4-inch TS “Y” cable, and the Channel 2 INPUT and OUTPUT are inserted on a keyboard channel using the same type of cable.
In this example, two S curve 231’s are used for the stereo main and for the 2-channel monitor mix. The mixer’s left and right outputs are connected to the first S curve 231’s inputs for the main PA speakers. Then, the outputs are connected to the inputs of the power amplifier connected to passive loudspeakers. For the monitor mix, the mixer’s AUX1 output is connected to the second S curve 231’s channel 1 input and AUX2 output is connected to the channel 2 input.
About Equalization The S curve 231 gives you fine control over shaping a sound, using a process called equalization. But there are few areas of sound engineering more misunderstood than equalization, and, just as good EQ can really help a sound, bad EQ can really hurt it, so read on... Every naturally occurring sound consists of a broad range of pitches, or frequencies, combined together in a unique way. This blend is what gives every sound its distinctive tonal color.
Grounding Techniques Hum and buzz are the biggest enemies you face when interconnecting a large number of different pieces of equipment to one another.
Using the S curve 231 with an RTA An RTA (Real Time Analyzer) is a device which measures the relative levels of multiple frequency areas. This device, in conjunction with a pink noise generator, is the perfect companion for your S curve 231. Together with a high quality microphone, these tools allow you to fine tune the overall frequency response of your audio system in any given environment (this procedure is sometimes known as “tuning” a room).
Using the S curve 231 to Remove Feedback One of the most important applications for the S curve 231 is removing feedback from an onstage monitor system. This procedure is sometimes called “ringing out,” since feedback usually begins with a slight ringing sound at the resonant frequencies where the loop between microphone and speaker is loudest.
S curve 231 Wiring Guide S curve 231 Wiring Guide There are several ways to interface the S curve 231, depending on your exact monitoring set-up. Follow the cable diagrams below for connecting your monitor system.
Specifications 1: Center frequencies (Hz) 20, 25, 31.5, 40, 50, 63, 80, 100, 125, 160, 200, 250, 315, 400, 500, 630, 800, 1 k, 1.25 k, 1.6 k, 2 k, 2.5 k, 3.15 k, 4 k, 5 k, 6.3 k, 8 k, 10 k, 12.5 k, 16 k, 20 k 2: Variable range ±6 dB or ±12 dB 3: Frequency response (unity) <10 Hz to 70 kHz -3 dB 4: THD+N, unity gain (20Hz to 20kHz) Less than 0.013% 5: Main level Max.
