CHAPTER 8 - ILLUSTRATED PARTS CATALOG
8-1 SPARE PARTS myc3-2,myc3-2j
ASSEMBLY Quantity Designation
5 1 Lower cover
10 1 Upper cover
15 1 Keypad
20 1 Antenna
25 1 FPC
30 1 Battery cover
35 4 Flap screw
40 1 Assembled loudspeaker
45 1 Antenna Screw
50 1 Battery
55 1 Volume Key
60 1 Spacer & metal dome
65 1 LCD pane
70 2 Screw protection
75 1 LCD
80 1 Flap upper housing
85 1 Main board
90 2 Flap stop
95 4 Body Screw
100 1 Microphone rubber
145 1 Vibrating device
150 1 Micro rubber
155 1 Side key
250 1 Flap lower housing
Contents REF MTB DTS 1- Indice D - November 10 2005 Page 8-1
