Technical information


Proc Sheet 1 18
myC3-2
5HPRYHDQG3ODFHWKHHTXLSSHGHOHFWURQLF
ERDUG
00,,,
1/2
7RROV
- Cross shaped screwdriver
- Tweezers
- Plait to be unsoldered
- Unsoldering braid
3UHOLPLQDU\RSHUDWLRQ
1. Remove the battery ( Proc Sheet 0 01 ).
2. Remove the lower casing of mobile ( Proc Sheet 1 01 ).
3. Remove the volume control key ( Proc Sheet 1 22 ).
4. Remove the micro rubber ( Proc Sheet 1 05 ).
5HPRYDOSURFHGXUH
1. Unstick (6) by means of the tweezers the side keypad.
2. Catch hold of the side keypad (7) and take out it of the slot (8) taking care not to damage the FPC (9).
3. Take out the equipped electronic card (1) by pulling apart the two spurs of maintains (5).
4. Unsolder the fixing surface of the FPC (4) by means of the unsoldering braid.
5. Lift the lock of the connector (6) downward.
6. Remove delicately the FPC of the equipped LCD (2) on the electronic board (1) .
7. Remove the equipped electronic board (1).
3ODFHPHQWSURFHGXUH
1. Position the FPC of the equipped LCD (2) in the connector of the new equipped electronic card (1).
2. Prepare the soldering surface and solder the fixing surface (4) to the electronic card (1).
3. close the lock (6) upwards to block the FPC of equipped LCD (2).
4. Position the equipped electronic card (1) in its slot.
5. Catch hold of the side keypad (7) and position in its slot (8).
6. Stick the side key (7) making sure it is correctly in contact with the plastic part of the lower casing of the
mobile.
)XUWKHURSHUDWLRQV
1. Place the micro rubber ( Proc Sheet 1 05 ).
2. Place the volume control key ( Proc Sheet 1 22 ).
3. Place the lower casing of mobile ( Proc Sheet 1 01 ).
4. Place the battery ( Proc Sheet 0 01 ).
Risk of the procedure :
• Mark the Lower and/or upper
housing.
• Damage the FPC of the LCD.
• Lose the micro rubber.
