User manual

1
1 Rear cover
2 Fax access door
3 Telephone handset
4 Auxiliary connector access
5 Radio module connector
6 PC connector
7 Operation panel
8 Front cover
9 Handset jack
10 Telephone line jack
11 Power supply jack
12 LCD display screen consisting of 2 lines
of 16 characters and 10 icons
13 Scan mode when sending faxes:
- normal: 2 icons off
- fine: fine icon lit
- photo: photo icon lit
14 Line icon:
Lit: communication in progress
Flashing: establishment of fax
communication or telephone commu-
nication in progress
15 Memory usage (0 to 100%)
16 Telephone icon: telephone in service
17 Fax icon: automatic fax reception
18 TAD icon: vocal answering machine in
service
19 Choice of scan mode when sending
faxes
20 Choice of reception mode
21 Numeric keypad
22 Alphabetic keypad
23 Start key: transmission of faxes or local
copy
24 @ key: used to enter the @ character in
e-mail addresses
25 Ctrl key: used in conjunction with any
letter on the keypad to access the symbols
shown above the alphabetic characters
26 Internet @ key: for faxing over the
Internet
27 Stop key: stop current operation or
confidential telephone (Mute)
28 Vocal messages lamp: presence of voice
messages on the answering machine
29 Vocal messages key: to listen to voice
messages
30 Fax messages key: to print faxes received
in memory
31 Fax messages lamp: presence of fax
messages stored in memory
32 Shift key ( ): used in conjunction with
any letter on the keypad to obtain a
capital letter
33 Key to increase speaker volume
34 Speaker key: use of line without unhook-
ing or amplified listening
35 Key to reduce speaker volume
36 Redial key: automatic recall of last
number dialled
37 Recall key: insert a pause in dialling or
PABX recall (Flash key)
38 Directory key: call a number in the
directory
39 Hold key: transfer a telephone com-
munication to a telephone connected in
parallel.
40 OK key: validation of selection displayed
on screen
41 Screen cursor: move right
42 Screen cursor: move up
43 Screen cursor: move left
44 C key: return to previous message dis-
played on screen
45 Menu key: access to various functions
46 Screen cursor: move down
