1.6 PRODUCT FEATURES
Temperature range
Normal range: -10°C to +55°C (fully compliant)
Extended range: -20°C to –10°C and +55°C to +70°C
(functional without any risk for the network)
Storage: -40°C to °85°C
Weight (in g) 10g
ESD ESD protection < 1.5 kV
Physical dimensions 34x54.4x3 mm (typical)
Connection
120 pins connector + 1 antenna connection + 1
battery connection
Power supply 3.45V to 4.5V range, 3.8V nominal.
Power consumption
1
Off mode: 120 uA (typ)
Stand-by mode: < 2.5 mA (typ)
Communication mode: 280 mA (typ at Pmax), 2.2 A
peak during TX slot
Power supply connector Dedicated connector
Battery charge management and interface
Battery charge management is included. The charger
interface is provided on 120 pins connector.
Antenna No antenna included in the module.
Frequency bands GSM850 + EGSM900 + DCS1800 + PCS1900
Voice codecs
Half Rate, Full Rate, Enhanced Full Rate,
Adaptive Multi Rate
GSM class Small MS
Transmit power
Class 4 (2W) for GSM850 / EGSM900
Class 1 (1W) for DCS1800 / PCS1900
Supported SIM card
3V SIM cards.
To prevent SIM card’s damages, the power supply of
the module has to be turned off before any
manipulation of the SIM card.
SIM slot
Not included on the module. Signals for the
management of the SIM card are provided on 120
pins connector
Network LED LEDR and LEDG management.
Audio up-link
2 differential inputs are provided for microphone
(accessories and handset).
Audio down-link
2 differential outputs are provided for non stereo
earphone and 1 differential output for accessories.
1
The power consumption is highly dependent on customer’s software and global environment of GSM Module
(MMI, Accessories,…).
