PNG Portable Network Graphics
RAM Random Access Memory
RF Radio Frequency
RI Ring Indication
RMS Root Mean Square
RTS Ready To Send
RX Reception
SIM Subscriber Identification Module
SMS Short Message Service
SRAM Static Random Access Memory
TBC To Be Confirmed
TBD To Be Defined
TX Transmission
UART Universal Asynchronous Receiver and Transmitter
USB Universal Serial Bus
USSD Unstructured Supplementary Service Data
VCO Voltage Controlled Oscillator
WAP Wireless Application Protocol
WBMP Wide Bitmap
1.5 CONVENTIONS
Throughout this document, DTE (Data Terminal equipment) indicates the equipment which masters and controls
the module device MO2XX by simply sending AT commands via its serial interface.
DCE (Data Communication Equipment) indicates the module device MO2XX.
