1.3 COMPLIANCE WITH FCC GUIDELINES
Devices incorporating MO2XX modules must be designed to maintain a minimum separation distance of 20 cm
between the antenna and the end user to satisfy RF exposure requirements for mobile transmitting devices.
1.4 TERMS AND ABBREVIATION
ADC Analog to Digital Converter
ADPCM Adaptive Delta Pulse Code Modulation
AFC Automatic Frequency Correction
ASIC Application Specific Integrated Circuit
BMP Bitmap
CODEC Coder-Decoder
CTS Clear To Send
DAC Digital to Analog Converter
DAI Digital Audio Interface
DCS Digital Communications System
DSP Data Signal Processor
DSR Data Set Ready
DTR Data Terminal Ready
EGSM Enhanced GSM
EMS Enhanced Messaging Services
ESD Electrostatic Discharge
ETS European Telecommunication Standard
GSM Global System for Mobile communication
GPRS General Packet Radio Services
IC Integrated Circuit
IEEE Institute of Electrical and Electronics Engineers
I/O Input / Output
IRDA Infra Red Device Application
ISO International Standards Organisation
ITU International Telecommunication Union
JPEG Joint Picture Expert Group
JTAG Joint Test Action Group
Kbps Kbits per second
LCD Liquid Crystal Display
LED Light Emitting Diode
LNA Low Noise Amplifier
Mbps Mbits per second
MIDI Musical Instrument Digital Interface
MMI Man Machine interface
PA Power Amplifier
PBCCH Packet Broadcast Channel
PCB Printed Circuit Board
PCS Personal Communication System
PLL Phase Locked Loop
