VBAT Power supply input
Bat Con
1,2
VRIO Power supply output 2
VBACKUP Power supply input 12
ANTENNE Analog bi directional HF Ant
TCK Digital input buffer (IDI091/ PE0201) Test point
TMS Digital input buffer (IDI091/ PS0201) Test point
TDIDIGIT Digital input buffer (IDI091/ PS0201) Test point
TDODIGIT Digital bi directional buffer (OUI431) Test point
TDIANALOG Digital bi directional buffer Test point
TDOANALOG Digital bi directional buffer Test point
BSCAN* Digital input buffer (IDI041/ PS0201) Test point
EMU0* Digital bi directional buffer (IDI091/OUO431/PS1001) Test point
EMU1* Digital bi directional buffer (IDI091/OUO431/PS1001) Test point
OUO231 : rated output current = 1mA (with Voh = Vccmin)
OUI431, OUK431, OUO431 :rated output current = 2mA (with Voh = Vccmin)
OUI831, OUK831 : rated output current = 4mA (with Voh = Vccmin)
