ANNEX 1 : IO description
IO name Type Pin N°
DAIRST Digital bi directional buffer (IDI041/OUK431) 116
DAIOUT Digital bi directional buffer (IDI041/OUK431) 115
DAIIN Digital bi directional buffer (IDI041/OUK431). Pull down 117
DAICLK Digital bi directional buffer (IDI041/OUI431). Pull down 118
USL1 Digital input buffer (IDI041/PS0201)
USL2 Digital output buffer (OUK431)
USL3 Digital output buffer (OUI431)
USL4 Digital output buffer (OUK431)
USL5 Digital output buffer (OUK431)
USL6 Digital bi directional buffer (IDG091/OUI431/PE1001)
USL7 Digital bi directional buffer (IDI041/OUI431/PS1001)
USL8 Digital bi directional buffer (IDI041/OUI431/PS1001)
USL9 Digital bi directional buffer (IDI041/OUI431/PS1001)
USL10 Digital bi directional buffer (IDI041/OUI431/PS1001)
MOD_ESCAPE*_CMD Digital bi directional buffer (IDI041/OUI431/PS1001) 18
USL11 Digital bi directional buffer (IDI041/OUI431/PS1001)
USL12 Digital output buffer (OUO431)
DTE_ESCAPE_CMD Digital output buffer (OUI431) 23
MOD_RESET_STATE Digital output buffer (OUI431) 24
MOD_UART_STATE Digital output buffer (OUI431) 25
MOD_FLOW_STATE Digital output buffer (OUI431) 26
MOD_ON_STATE Digital output buffer (OUI431) 27
MOD_ON*_CMD Digital input 113
SIMVCC Power supply output 6
SIMRST Digital output buffer 5
SIMCLK Digital output buffer 4
SIMIO Digital bi directional buffer 7
SIMCD Digital input buffer (IDI091) 114
HSMICIP Analog audio input 52
HSMICIN Analog audio input 53
HSOL Analog audio output 50
HSOR Analog audio output 49
MICIP Analog audio input 63
MICIN Analog audio input 62
HPP32 Analog audio output 46
HPN32 Analog audio output 47
HPP8 Analog audio output 56
HPN8 Analog audio output 57
USL13 Digital bi directional buffer (IDG091/OUI431/PE1001)
RI Digital bi directional buffer (IDG091/OUO431/PS1001) 109
DSR Digital bi directional buffer (IDG091/OUI431/PE1001) 94
DCD Digital output buffer (OUI831) 110
DTR Digital bi directional buffer (IDI091/OUI831) 95
CTS Digital output buffer (OUI831) 82
RTS Digital bi directional buffer (IDI091/OUO431) 83
