7. ENVIRONMENTAL SPECIFICATION
Parameter
Min Max
Ambient temperature
Normal range
-10°C +55°C
Ambient temperature
Extended range
-20°C +70°C
Storage temperature -40°C +85°C
Long damp heat
Operating conditions
Tested at +60°C, 95% RH during 504 hours
Short damp heat
Storage and
transportation conditions
Tested at +40°C, 95% RH during 96 hours
Normal Range, from -10°c to +55°c:
Inside this normal range, full compliance with GSM standards is guaranteed by SAGEM.
Certification tests reports applies to modules operating in this interval.
Extended Range, from -20°c to -10°c and from +55°c to +70°c:
Inside this extended range, the operability is guaranteed by SAGEM. However, there is not a full certification test
report in this range.
Practically, SAGEM performs non regression tests in this range in order to ensure that the module can attach to the
network and handle a call.
Some performances may remain under the normal GSM expectation (sensitivity, RXlev 1 or 2 dB lower, TX
emitting power slightly weaker).
Out of operational range:
No operation is guaranteed by SAGEM out of the operational range. No operating tests are made below -20°c and
above +70°c.
