6.13 RESET
MOD_RESET*_CMD is active at low state
It has the following characteristics:
Signal Min Max Remarks
V
L
(V) - 0.3 VBAT
V
H
(V) 0.7 VBAT -
Treset (ms) 65 -
Electrical levels TBC
NB: The reset signal resets all the system including backup.
6.14 SPARE IO
IO5, 6, 7 have the following characteristics:
V
L
(V) V
H
(V) Remarks State after RESETSignal
Min Max Min Max
Input -0.5 +0.8 +2.03 +3.2
Output - +0.59 +2.32 -
IO 5,6,7: PD
PU
I
out
max = 2mA
6.15 CLOCKS
CLK13M and CLK32K have the following characteristics:
V
L
(V) V
H
(V)Signal
Min Max Min Max
Remarks
CLK13M - +0.59 +2.32 -
CLK32K - 0,297 1,32 -
6.16 JTAG INTERFACE
TCLK, TMS, TDI, TDODIGIT, TDIANALOG, BSCAN*, EMU0*, EMU1* have the following characteristics:
V
L
(V) V
H
(V)Signal
Min Max Min Max
Remarks
TMS, TDI,
TDIANALOG,
BSCAN*
-0.5 +0.8 +2.03 +3.2 PU
TCK -0.5 +0.8 +2.03 +3.2 PD
TDODIGIT,
TDOANALOG,
- +0.59 +2.32 -
EMU0*, EMU1* - +0.59 +2.32 - PU
