6.2 VRIO
Signal Min Typ Max Remarks
Voltage level (activ
mode)
2.70V 2.80V 2.90V
Voltage level (sleep
mode)
2.70V 2.80V 3.00V
Current capability
Active mode
- - 10mA
Current capability
Sleep mode
- - 0.5mA
Rise time -
10
µ
s
-
6.3 DAI INTERFACE
DAIRST, DAIIN, DAICLK and DAIOUT have the following characteristics:
V
L
(V) V
H
(V)Signal
Min Max Min Max
Remarks
DAIRST -0.5 +0.8 +2.03 +3.2
DAICLK -0.5 +0.8 +2.03 +3.2 PD 100K
DAIIN -0.5 +0.8 +2.03 +3.2 PD 100K
DAIOUT - +0.59 +2.32 -
6.4 NETWORK LED
LEDR and LEDG have the following characteristics:
VL (V) VH (V)Signal
Min Max Min Max
Remarks
State after RESET
LEDR (out) - -
To be verified
LEDG (out) - -
To be verified
6.5 SERIAL INTERFACE (µWIRE)
DIMIW, DOMIW, CKMIW, CSMIW1* have the following characteristics:
V
L
(V) V
H
(V)Signal
Min Max Min Max
Remarks
DIMIW -0.5 +0.8 +2.03 +3.2 PU 100K
DOMIW - +0.59 +2.32 -
CKMIW - +0.59 +2.32 -
CSMIW1* - +0.59 +2.32 -
6.6 SIM
VL (V) VH (V)Signal
Min Max Min Max
Remarks
State after RESET
SIMRST
SIMCLK
SIMIO
SIMVCC
SIMCD
Fully compliant to the GSM11.11 and
ISO/IEC 7816-3 standards
Fully
compliant to
the GSM11.11
and ISO/IEC
7816-3
standards.
PD
