LEDG Imax = 4 mA Electrical level : to be verified
LEDR Imax = 4 mA Electrical level : to be verified
VBAT Vmax = 5V Electrical limitation : Vmax = 4.5V
V56 available Hardware incompatibility : not available
VRIO Current capability sleep mode = 1 mA Electrical limitation :
Current capability sleep mode = 0.5 mA
ADC2 ADC1 Hardware interfacing :
5.7Kohms on MO190
12pF on MO2XX
IO5 New signal
IO6 New signal
IO7 SPRIO =CMDSW1, Imax = 4 mA Electrical limitation : IO7, Imax = 2 mA
TSPACTEXT New signal
STBYCAM New signal
ALIMLCD available Not available
SPI bus Available Not available
Parallel bus (16bit) Available Not available
