D.A.I GSM DAI test mode interface
UART1 interface with flow control
Up to 115.2 Kbaud with auto bauding.
Full flow control signals (+2.8V) are provided on ball-
out.
If a full compliant RS232 (+/-5V) serial interface is
needed:
The drivers (like MAX3232, ST3237CD, …) are not
included in the module and have to be added on the
main PCB.
A proven schematic to build the RS232 interface is
provided in application note.
Data/command multiplexing
Hardware management of data/command
multiplexing on the serial link UART1
Power management
Hardware management of sleeping and waking in
module /DTE architecture
UART2 interface Up to 115.2 Kbaud.
Data services GPRS, CSD, Fax
Supplementary services (supported via AT
commands, refer to SCT TMO MOD SPEC 465 B)
Caller Line Identification, Call Waiting, Call Hold, Call
Forwarding, Multiparty, Call Barring, Advice of
Charge, USSD, CPHS
Reset pin Available (reset of all the system including backup)
Power on pin Available
General purpose I/Os pin 3 x I/O, 1 interrupt, 1 ADC available
GPRS
SMG 31bis, Multi slot class 10, class B terminal,
PBCCH support
GSM/DCS certification GCF-CC V.3.16.0 and GT.01
PCS certification NAPRD.03 (V.2.10.1)
