Technical Specifications

Notes: The jetted heater is designed to maintain water temperature during operation. It will not heat cold water to desired bathing temperature.
Tub is supported by the frame and five integrated adjustable feet, no additional support required. Refer to installation instructions supplied with tub for
additional information. Provide suitable reinforcement to sub floor for all supports.
Our products are in compliance with the following codes: Uniform Plumbing Code UPC®; National Plumbing Code of Canada; International Plumbing
Code IPC®
Our products conform to the following standards: ASME A112.19.7, ASME A112.19.15; CSA B45, CSA B45.5; CSA C22.2 No. 218.2; UL-1795; ANSI Z124.1.2
Our products are listed with: c ETL us
IMPORTANT: Dimensions of fixtures are nominal, may vary and are subject to change or cancellation. No responsibility is assumed for use of
superseded or voided leaflet.
SS9OD5232 VALUE SERIES
52" X 32" WALK-IN BATH
© 2017 Safety Tubs Company, LLC
To Be Specified - Required:
 Drain Configuration: Left (L) or Right (R)
 Color: White (WH) or Biscuit (BC)
Options:
 Handshower Glide Bar: 9HSB
 24 inch Grab Bar: 9GB-24
 Neck Rest: 9NR
SS9OD5232XS-XX Soaking Tub
• Tub Extender Kit to fill 60" space
• Available in White or Biscuit and in Left Hand or Right Hand
Door/Drain Configuration
• Outward opening door with watertight door system with a
lifetime warranty on the door seal
• Built-in chair height seat
• Polished chrome trim and cable driven waste and overflow
• Built-in safety bar and textured tub floor
• Patented Minute Drain® fast water removal system
• Premium fast-fill tub faucet and handheld showering wand
• Full seat transfer
SS9OD5232XJ-XX Jet Massage System
Combines all of the features of the Soaking Tub, plus:
• Jetted in-line heater
• 6 massage jets with variable flow
• Legs-only massage
SS9OD5232XD-XX Air Massage System
Combines all of the features of the Soaking Tub, plus:
• Single speed heated blower
• 21 seat and floor air injectors
• Automatic purge cycle
SS9OD5232XD-XX Dual System
Combines all of the features of the Soaker Tub,
the Jet Massage and the Air Massage Systems
for the ultimate therapeutic bathing experience.
GENERAL SPECIFICATIONS FOR SS9OD5232XX-XX
WALK-IN BATHTUB
INSTALLED SIZE __________ 52 x 32 x 40 In. (1320 x 813 x 1016mm)
WEIGHT ___________________________________ 161 Lbs. (73 Kg.)
WEIGHT w/WATER ________________________ 828 Lbs. (376 Kg.)
OPERATING GALLON _________________________80 Gal. (303 L.)
FLOOR LOADING _______________72 Lbs./Sq. Ft. (351 Kgs/Sq. m.)
(PROJECTED AREA)
CUBE (FT
3
) __________________________________________ 38.5
