CFIP Lumina series
Microwave Radio Systems
III CFIP Lumina Tx power
Standard/High Tx Power, dBm
Modulation
6, 7 GHz 11, 13, 15 GHz 18, 23 GHz 24 GHz
4,5,6
38 GHz
4QAM +19 / +27 +19 / +25 +19
-20…0 +17
16QAM +18 / +26 +18 / +24 +18
-20…-1 +16
32QAM +17 / +25 +17 / +23 +17
-20…-2 +15
64QAM +15 / +23 +15 / +21 +15
-20…-4 +13
128QAM +15 / +23 +15 / +21 +15
-20…-4 +13
256QAM +12 / +20 +12 / +18 +12
-20…-7 +10
4
For non-degraded Rx sensitivity refer to Technical Description (TD) for maximum Tx level according to Rx level observed.
5
Tx power should not exceed EIRP limitation. Please consult the local spectrum regulating authority.
6
Output Tx range may differ for previous hardware and software versions.
