CFIP Lumina series
Microwave Radio Systems
III CFIP Lumina Rx sensitivity, payload capacity
BW
1
, MHz
Modulation FEC
2
6 GHz 7 GHz 11 GHz 13 GHz 15 GHz 18 GHz 23 GHz
24
4
GHz
38 GHz
Capacities,
Mbps
4QAM Strong -87.5 -86,5 -87.5 -87 -87 -87 -86 -86 -82 63
16QAM Strong -81.5 -80,5 -81 -81 -80.5 -81.5 -80 -80 -76 125
32QAM Strong -79 -77,5 -78.5 -78 -78 -78.5 -77.5 -77.5 -73.5 158
64QAM Strong -76 -75 -75.5 -75 -75 -76 -74.5 -74.5 -70.5 207
128QAM Strong -73 -72 -72.5 -72 -71.5 -72.5 -71.5 -71.5 -67.5 249
Strong -69.5 -68 -68.5 -68,5 -68 -69.5 -68 -68 -64 290
50
256QAM
Weak -66 -64,5 -64.5 -64,5 -64 -66 -64.5 -64.5 -60.5 313
4QAM Strong -87 -85,5 -87 -86,5 -86 -87 -85.5 -85.5 -81.5 72/67
3
16QAM Strong -81 -80 -80.5 -80 -79.5 -80.5 -79.5 -79.5 -75.5 145/135
3
32QAM Strong -78 -77 -78 -77,5 -77 -77.5 -76.5 -76.5 -72.5 186
64QAM Strong -75.5 -74,5 -74.5 -74,5 -74 -75.5 -74 -74 -70 241
128QAM Strong -72 -71 -71.5 -71,5 -71 -72 -70.5 -70.5 -66.5 289
Strong -68.5 -67,5 -68 -67,5 -67 -68.5 -67 -67 -63 337
56
256QAM
Weak -64 -63 -63.5 -63 -62.5 -64.5 -62.5 -62.5 -58.5 366
1
According to ANSI channel plan
2
Forward Error Correction (FEC) can be optimized either for sensitivity (Strong FEC) or for capacity (Weak FEC)
3
Higher capacity is available in 16QAM and 4QAM if using 32QAM-256QAM with ACM enabled
4
For non-degraded Rx sensitivity refer to Technical Description (TD) for maximum Tx level according to Rx level observed.
