Manual

© SAF Tehnika JSC
Ver. 1.10, 2012
CFIP Lumina series
Microwave Radio Systems
III CFIP Lumina Rx sensitivity, payload capacity
BW
1
, MHz
Modulation FEC
2
6 GHz 7 GHz 11 GHz 13 GHz 15 GHz 18 GHz 23 GHz
24
4
GHz
38 GHz
Capacities,
Mbps
4QAM Strong -92 -91 -91 -91 -90.5 -91.5 -90.5 -90.5 -86.5 24
16QAM Strong -84.5 -84,5 -85 -85 -84.5 -85.5 -83 -83 -79 49
32QAM Strong -82 -82 -82 -82 -81.5 -82.5 -80.5 -80.5 -76.5 63
64QAM Strong -80 -79 -79 -79 -78.5 -79.5 -78.5 -78.5 -74.5 82
128QAM Strong -77 -76 -76 -76 -75.5 -76.5 -75.5 -75.5 -71.5 98
Strong -73.5 -72 -72 -73 -72 -73 -72 -72 -68 115
20
256QAM
Weak -70 -66 -67 -67 -66.5 -67.5 -68.5 -68.5 -64.5 125
4QAM Strong -90 -89 -89.5 -89,5 -89 -89.5 -88.5 -88.5 -84.5 37
16QAM Strong -84 -83 -83.5 -83 -82.5 -83.5 -82.5 -82.5 -78.5 74
32QAM Strong -81 -80 -80.5 -80,5 -80 -80.5 -79.5 -79.5 -75.5 95
64QAM Strong -78.5 -77 -77.5 -77,5 -77 -78 -77 -77 -73 123
128QAM Strong -75.5 -74 -74.5 -74,5 -74 -75 -74 -74 -70 147
Strong -72 -70,5 -71 -71 -70.5 -71.5 -70.5 -70.5 -66.5 172
30
256QAM
Weak -69 -68,5 -67 -66,5 -66.5 -69 -67.5 -67.5 -63.5 184
4QAM Strong -89 -87,5 -88 -88 -88 -88 -87.5 -87.5 -83.5 50
16QAM Strong -82.5 -81,5 -82 -82 -81.5 -82.5 -81 -81 -77 98
32QAM Strong -80 -78,5 -79.5 -79,5 -79 -79.5 -78.5 -78.5 -74.5 127
64QAM Strong -77 -76 -76.5 -76 -76 -77 -75.5 -75.5 -71.5 164
128QAM Strong -74 -73 -73.5 -73 -72.5 -73.5 -72.5 -72.5 -68.5 196
Strong -70.5 -69,5 -69.5 -69,5 -69 -70.5 -69 -69 -65 229
40
256QAM
Weak -68 -67 -65.5 -65 -65 -67.5 -66.5 -66.5 -62.5 245
