Replacement Part List

7
48 V ELECTRIC ZERO TURN MOWER − MODEL NOS. RY48ZTR75, RY48ZTR100
4
1
4
2
2
3
5
FIGURE D
REAR CROSS MEMBER ASSEMBLY
1 996983001 Rear Cross Member, Frame .............................................................1
2 997089001 Bolt (M8 x 70 mm, Hex Hd.) ............................................................2
3 997051001 Tow Hitch .........................................................................................1
4 994867001 Flange Nut (M8) ...............................................................................2
5 997136001 Bolt (M8 x 55 mm, Hex Hd.) ............................................................2
KEY PART
NO. NUMBER DESCRIPTION QTY
The model number will be found on a label under the seat. Always mention the model number in all correspon-
dence regarding your LAWN MOWER or when ordering replacement parts.
