Replacement Part List

48 V ELECTRIC ZERO TURN MOWER − MODEL NOS. RY48ZTR75, RY48ZTR100
4
PLASTIC ASSEMBLY
The model number will be found on a label under the seat. Always mention the model number in all correspondence regarding your LAWN MOWER
or when ordering replacement parts.
1 994989001 Screw (M6 x 16 mm, Torx Pan Hd.) ...............................................22
2 994785001 Clip-On Nut (M6) ............................................................................12
3 997064001 Right Trim Cover ..............................................................................1
4 997075001 Charger Port Door Spring ................................................................1
5 997076001 Storage Box Spring .........................................................................2
6 997061001 Center Trim Cover ............................................................................1
7 997066001 Front Access Panel ..........................................................................1
8 997070001 Storage Box Hinge Pin ....................................................................2
9 997067001 Charger Port Door ............................................................................ 1
10 997068001 Storage Box Lid ...............................................................................2
11 997065001 Center Access Panel .......................................................................1
12 997069001 Charger Port Door Hinge Pin ...........................................................1
13 997063001 Left Trim Cover ................................................................................1
14 997062001 Rear Trim Cover ...............................................................................1
15 997087001 Main Relay Guard ............................................................................1
16 996297001 Screw (M4 x 10 mm, Pan Hd.) .........................................................2
KEY PART
NO. NUMBER DESCRIPTION QTY
FIGURE B
