Replacement Part List

48 V ELECTRIC ZERO TURN MOWER − MODEL NOS. RY48ZTR75, RY48ZTR100
24
The model number will be found on a label under the seat. Always mention the model number in all correspondence regarding your LAWN MOWER
or when ordering replacement parts.
LABELS
FIGURE Q
KEY PART
NO. NUMBER DESCRIPTION QTY
1 099749015036 DATA LABEL (RY48ZTR75) ....................................1
099749015046 DATA LABEL (RY48ZTR100) ..................................1
2 099749015045 DECK LIFT LABEL .................................................1
3 099749015047 CHARGING PORT LABEL, ENGLISH .................... 1
099749015048 CHARGING PORT LABEL, SPANISH ....................1
4 099749015039 SUBBRAND LABEL, RIGHT (RY48ZTR75) ............1
099749016001 SUBBRAND LABEL, RIGHT (RY48ZTR100) ..........1
5 099749015049 RPL LABEL, ENGLISH ...........................................1
099749015050 RPL LABEL, SPANISH ........................................... 1
6 099749015060 RYOBI LABEL, FRONT ..........................................1
7 099749015061 RYOBI LOGO, RIGHT ............................................1
8 099749015062 RYOBI LABEL, LEFT ..............................................1
9 099749015063 SUBBRAND LABEL, LEFT (RY48ZTR75) ...............1
099749016002 SUBBRAND LABEL, LEFT (RY48ZTR100) .............1
10 099749015064 FLOOR DANGER LABEL, ENGLISH .....................1
099749015065 FLOOR DANGER LABEL, SPANISH ..................... 1
11 099749015068 INSTRUCTION LABEL, ENGLISH ..........................1
099749015069 INSTRUCTION LABEL, SPANISH ..........................1
12 940851219 NO HANDS CPSC DANGER LABEL, ENGLISH ....2
940851226 NO HANDS CPSC DANGER LABEL, SPANISH ....2
13 940851207 DECK DANGER LABEL, ENGLISH ........................ 1
14 940851208 DISCHARGE DANGER LABEL, ENGLISH ............. 1
940851228 DISCHARGE DANGER LABEL, SPANISH .............1
KEY PART
NO. NUMBER DESCRIPTION QTY
