Replacement Part List

48 V ELECTRIC ZERO TURN MOWER − MODEL NOS. RY48ZTR75, RY48ZTR100
18
FIGURE M
CHARGER PORT ASSEMBLY
The model number will be found on a label under the seat. Always mention the model number in all correspondence regarding your LAWN MOWER
or when ordering replacement parts.
1
2
3
KEY PART
NO. NUMBER DESCRIPTION QTY
1 996515001 Charger Receptacle 3 Pin With Thermistor .......... 1
2 996514001 American Standand Charger ................................ 1
3 994989001 Screw (M6 x 16, Torx Hd.) ..................................... 4
