Replacement Part List

48 V ELECTRIC ZERO TURN MOWER − MODEL NOS. RY48ZTR75, RY48ZTR100
16
1 994970001 PTO ....................................................................... 1
2 994989001 Screw (M6 x 1.00 x 16, Torx Hd.) .......................... 4
3 994966001 Light Switch Button .............................................. 1
4 997080001 Button Switch, Drive Speed .................................. 1
5 996288001 Warning Tag .......................................................... 1
6 997071001 Control Panel Face Plate ...................................... 1
7 997078001 Fuel Gauge, ZTR ................................................... 1
8 996361001 Spring Washer 2 ................................................... 3
9 994963001 USB Module .......................................................... 1
10 996362001 Spring Washer 3 ................................................... 1
11 997082001 PTO Gasket .......................................................... 1
12 996049001 Key, Riding Mower ................................................ 1
13 997079001 Button Switch, Blade Speed ................................. 1
14 994964001 Key Module ........................................................... 1
The model number will be found on a label under the seat. Always mention the model number in all correspondence regarding your LAWN MOWER
or when ordering replacement parts.
2
5
12
10
1
14
3
4
8
7
9
13
11
6
KEY PART
NO. NUMBER DESCRIPTION QTY
FIGURE K
CONTROL PANEL ASSEMBLY
