Replacement Part List

48 V ELECTRIC ZERO TURN MOWER − MODEL NOS. RY48ZTR75, RY48ZTR100
15
FIGURE J
1 997002001 Foot Rest Plate ..................................................... 1
2 994989001 Screw (M6 x 1 x 16, Torx Hd.) ............................. 13
3 997001001 Floor Plate ............................................................. 1
4 994957001 Light Assembly, Riding Mower ............................. 2
5 997081001 Anti Slip Decal Package ........................................ 1
KEY PART
NO. NUMBER DESCRIPTION QTY
FLOOR PANEL ASSEMBLY
The model number will be found on a label under the seat. Always mention the model number in all correspondence regarding your LAWN MOWER
or when ordering replacement parts.
2
5
3
5
2
4
2
2
1
4
5
