Replacement Part List

48 V ELECTRIC ZERO TURN MOWER − MODEL NOS. RY48ZTR75, RY48ZTR100
14
1 997013001 Deck Lift Axle Mount ............................................ 2
2 997023001 Deck Lift Lever Torsion Spring .............................. 1
3 994770001 Lock Washer (M8) ................................................. 3
4 997093001 Deck Lift Linkage Spacer ...................................... 2
5 996046001 Bolt (M8 x 25 mm) ................................................. 3
6 994996001 Washer (M10 x 20) .............................................. 10
7 994892001 Cotter Pin .............................................................. 2
8 994771001 Washer (M8) .......................................................... 3
9 997018001 Deck Lift Linkage .................................................. 2
10 997126001 Hanger Stud, ZTR ................................................. 2
11 994763001 Washer (17 x 30 x 3t) ............................................ 2
12 997015001 Deck Lift Axle Bushing, Bottom ............................ 2
13 997128001 Cut Height Memory Plug ...................................... 1
14 997024001 Detent Plate .......................................................... 1
15 997017001 J Hook, Deck Hanger ............................................ 2
16 997019001 Deck Lift Linkage Bushing .................................... 2
KEY PART
NO. NUMBER DESCRIPTION QTY
DECK LIFTING ASSEMBLY
17 997022001 Deck Lift Lever ...................................................... 1
18 997025001 Deck Lift Spring .................................................... 2
19 994891001 Washer (M13) ........................................................ 3
20 997016001 Deck Lift Linkage and Axle Assembly .................. 1
21 994833001 E-Clip, 12 mm Shaft Dia. ...................................... 2
22 994972001 Decklift Handle ...................................................... 1
23 997014001 Deck Lift Axle Bushing,Top ................................... 2
24 996999001 Flange Nut (M12) .................................................. 1
25 996263001 Nut (M10 x 1.5) ..................................................... 8
26 997021001 J Hook, Front Deck Hanger .................................. 1
27 997097001 Front Deck Hanger Pivot Axle ............................... 1
28 996233001 Cotter Pin .............................................................. 4
29 997106001 Hex Head (M10 x 30 mm) ..................................... 4
30 994998001 Lock Spring Washer (10.9 x 16.1 x 2.6t) ............... 4
31 997140001 Hinge Cotter Pin ................................................... 1
KEY PART
NO. NUMBER DESCRIPTION QTY
The model number will be found on a label under the seat. Always mention the model number in all correspondence regarding your LAWN MOWER
or when ordering replacement parts.
FIGURE I
