Replacement Part List

48 V ELECTRIC ZERO TURN MOWER − MODEL NOS. RY48ZTR75, RY48ZTR100
10
1 997020001 Deck, 42 in. ........................................................... 1
2 996251001 Flange Lock Nut (M6 x 1) .................................... 16
3 996205001 M10 x 70 Shoulder Bolt (16 OD 47.5 mm) ............ 2
4 996201001 Threaded Stud (M6 x 35 mm) ............................... 4
5 997026001 Deck Motor ........................................................... 2
6 997027001 Blade Adapter ....................................................... 2
7 996192001 Lock Nut (M10 X 1.5 mm, Hex Hd.) ...................... 2
8 997083001 Deck Motor Cover, Bottom ................................... 2
9 996057001 Flange Bolt (M6 x 25 mm, Hex Hd.) ...................... 4
10 996039001 Deck Bagger Chute Mounting Shaft ..................... 1
11 996034001 Flat Washer (M6, 18 mm OD) ................................ 1
12 997028001 Blade Retainer Washer ......................................... 2
13 682282001 Blade (21 in.) ......................................................... 2
14 994867001 Flange Nut (M8) .................................................... 2
15 996250001 Screw (M6 x 40 mm, Torx Hd.) ............................. 1
16 994791001 Carriage Bolt (M6 x 16 mm) .................................. 3
17 997084001 Deck Motor Cover, Top ......................................... 2
18 996050001 Carriage Bolt (M8 x 20 mm) .................................. 2
19 996355001 Spring Washer ...................................................... 2
20 996261001 Lock Nut (M10 x 1.25) ........................................... 2
21 997074001 Deck Baffle (42 in.) ................................................ 1
22 996265001 Front Deck Roller Wheel (127 Dia.) ....................... 2
23 997127001 Discharge Chute Mounting Bracket ...................... 1
KEY PART
NO. NUMBER DESCRIPTION QTY
DECK ASSEMBLY PARTS LIST
KEY PART
NO. NUMBER DESCRIPTION QTY
The model number will be found on a label under the seat. Always mention the model number in all correspondence regarding your LAWN MOWER
or when ordering replacement parts.
FIGURE F
