Connecting to AC PowerThe SC-1 system includes two (2) AC power cords (one each for the DHD Controller and
projector).
DHD Controller: Plug the female end of one power cord into the AC receptacle on the
rear of the DHD Controller. Connect the other end to your AC power source
(100
to 240 VAC).
Projector: Similarly connect the SC-1 to a nearby AC outlet. The input voltage must be
between 200 and 240 VAC.
The LED status window displays an active pattern of segments to
indicate the projector is changing its state from powered down to
standby. At this point, the projection head is in a type of “standby”
mode only; the light engine compartment fans are running but the
rest of the projection head is off. “--” appears in the display when
the projector is ready to be turned on.
AutoScope Lens Motor: With AutoScope-equipped projectors, a third power cord is
provided for the lens motor. Plug the female end of the AC power cord into the AC input
on the rear of the lens motor assembly (see
Figure 3-19). Connect the other end to a
110 VAC power source.
The SC-1 requires a dedicated, 220-VAC/30A circuit. Connect
only the SC-1 to this circuit.
The input voltage to the AutoScope lens motor must be between
100 and 120 VAC. Do not connect the AutoScope lens motor
to a 200-240
VAC power source!
Caution
Caution
