Throw Distance Ranges: Table 3-3 lists the available lens options for the SC-1 and their
associated throw ratios.
Table 3-3. SC-1 Lens Options and Throw Ratios
Signature
Lens
Option
(Note 2)
Throw Ratio
with Primary
Lens Only
Throw Range in
inches, with a
96x54-inch
(1.78:1) Screen
Throw Range in
inches, with a
102.6x54-inch
(1.90:1) Screen
(Note 3)
Throw Ratio
with Primary
Lens and
Anamorphic
Lens
Throw Range in
inches, with a
126.9x54-inch
(2.35:1) Screen
(Note 3)
Min. Max. Min. Max. Min. Max.
A
1.40-1.58 134.40 151.68
Not Applicable (Note 2)
1.32-1.50 135.43 153.90
B
1.57-1.93 150.72 185.28
1.48-1.81 151.84 185.70
C
1.96-2.55 188.16 244.80
1.84-2.40 188.78 246.24
1.49-1.93 189.08 244.92
D
2.37-3.19 227.52 306.24
2.25-2.99 230.85 306.77
1.80-2.41 228.42 305.83
E
3.22-4.56 309.12 437.76
3.02-4.28 309.85 439.13
2.44-3.45 309.64 437.80
F
4.30-6.00 412.80 576.00
4.03-5.63 413.48 577.64
3.05-4.26 387.04 540.59
G
5.50-8.50 528.00 816.00
5.16-7.97 529.42 817.72
3.91-6.03 496.18 765.21
Notes:
1. Throw distance does not affect image quality, provided these ranges are taken into account.
2. Only the Signature C, D, E, F and G lenses can be used with the optional CineWide (secondary
anamorphic) lens. Doing so affects the throw distances as shown here.
3. The “1.90:1” throw distances are for reference only. The SC-1 has a native resolution of 2048 x
1080, which is about a 1.90:1 native aspect ratio. With most source material, the SC-1 only uses
the center, 1,920 pixels in each row (1920
x 1080 = 16:9 or 1.78:1 native aspect ratio).
