7. IR SENSOR
Receives IR commands from the TheaterMaster remote control.
8. INPUT 2 (DVI)
Press this button to select projector Input 2 (HDMI output from the DHD Controller).
9. Menu Navigation Buttons:
UP BUTTON ( )
Used to move the menu cursor up in the SC-1 menu system.
LEFT BUTTON ( )
Used to move the menu cursor left in the SC-1 menu system.
DOWN BUTTON ( )
Used to move the menu cursor down in the SC-1 menu system.
RIGHT BUTTON ( )
Used to move the menu cursor right in the SC-1 menu system.
ENTER BUTTON
When an item is highlighted on the On-Screen Display, press ENTER to select the
item.
10. MENU
Press this button to show or hide the projector menus.
11. AUTO SETUP
Press this button to initiate an automated process in which the projector optimizes
critical display parameters for the current source.
The SC-1 has its own internal menu system, separate from that of
the DHD Controller. However, it is intended for use by trained
service personnel only.
Note
