Introduction
4 Runco SC-1 Owner’s Operating Manual
PRE
L
IMINAR
Y
Key Features and Benefits The SC-1 offers these key features and benefits:
• Native Resolution: 2048 x 1080
• Three-chip Digital Light Processing (DLP™) system
• Two HDMI Inputs (on DHD Controller) with High-bandwidth Digital Content Protection
(HDCP)
• HDTV Compatible
•CinOptx™ Signature lens options for stunning sharpness and throw distance flexibility
• Internal electromechanical shutter for quick picture mute and black stand-by
• Inverse telecine deinterlacing of film-originated, standard and high-definition interlaced
material with 3:2 pull-down (60 fps) or 2:2 pull-down (50 fps)
• Auto-setup with seamless cut-and-fade source switching
• Control via built-in keypad, infrared (IR) remote or serial commands via RS-232
• LED for 2-digit error codes, plus LCD for text-based status display
• Incoming AC voltmeter
Parts List Your SC-1 is shipped with the following items. If any items are missing or damaged,
please contact your Runco dealer or Runco Customer Service at (800) 23-RUNCO.
• Signature Cinema™ SC-1 DLP Projector and DHD Controller
• Remote Control Unit and two (2), AAA-size batteries
• TheaterMaster Remote Control Unit and four (4), AAA-size batteries
• Power Cords: 110-VAC (for DHD Controller) and 220-VAC (for projector)
• RJ-11 Telephone Cable, 50 feet (15.24 meters)
• Serial Port Adapter, RJ-11 Female to DB-9 Male
• Rack-mounting brackets and hardware for the DHD Controller
• Warranty information and registration card
• Runco SC-1 Owner’s Operating Manual (this document)
Optional Accessories:
• CineWide™ technology (fixed, secondary anamorphic lens)
• CineWide™ with AutoScope™ system (secondary anamorphic lens and motorized
mount)
• External Power Supply and Lamp Ballast
➤
➤
