Specifications

Serial Communications
Runco SC-1 Owner’s Operating Manual 105
PRE
L
IMINAR
Y
Miscellaneous Commands
BKGND -100/100 YES Sets the background color for letterbox
or 4:3 aspect ratio
(-100 = black; 100 = white)
BKGND? NA NA Returns background setting value
DATE? NA NA Returns software release date
DISPLAY? NA NA Returns display device input source
value
HDINPUTRES NA YES Sets YPbPr input resolution and refresh
rate for HD1/HD2, as follows:
0 = 480i
1 = 480p
2 = 576i
3 = 576p
4 = 720p / 60 Hz
5 = 1080i / 60 Hz
6 = 720p / 50 Hz
7 = 1080i / 25 Hz
Any other value = Auto
HDMI1080IBYPASS 0/1 YES Sets Digital (1080i) Bypass off (0) or on
(1)
HWVER? NA NA Returns hardware version number
INRES? NA NA Returns input resolution
LENS1? NA NA Returns Lens 1 configuration
LENS2? NA NA Returns Lens 2 configuration
SWVER? NA NA Returns software version number
TRIGGER 1/3 YES Assigns trigger to currently-selected
aspect ratio
Table 6-1. Serial Commands (continued)
Command
Parameter
(min/max)
Value
Stored?
Description
