Intercom System User Manual

3
CHAPTER 1
Menu List for DKP-8, DKP-12, and KP-12 Keypanels
TOP LEVEL MENU. With the MENU indicator OFF, turn the SELECT control to view the following items in the call waiting
window.
MENU ITEM DESCRIPTION
--- See “Top Level Menu, - - - - (Clear call
waiting)” on page 15.
Clear call waiting. Default condition of call waiting window.
Call List See “Top Menu Level, Call List
Names” on page 16.
Up to 4 names that are not assigned to keys are saved for quick talk using SELECT control.
DISPLAY Menu See “Top Level Menu, Display” on page 16.
CHANS ON Displays a list of destinations that are currently communicating with the keypanel.
EXCLUSIVE Displays keys assigned Exclusive rights.
GROUP 1-4 Displays keys assigned to groups using GROUP feature on KEY OPT menu.
KEY ICOM Displays intercom system to which each talk key is assigned.
KEY TYPE Displays type of key assignment for all assigned talk keys (P-P, PL, IFB, etc.)
LEVEL 2 Displays any level 2 talk key assignments.
LISTEN Displays all listen key assignments
PAG E USE Displays which setup pages are currently being used and where.
PORT NUM Displays the intercom port number that the keypanel is connected to.
SOLO Displays any keys that have the SOLO option assigned from the KEY OPT menu.
VERSION Displays the firmware version for the keypanel.
KEY LIST See “Top Level Menu, Level” on
page 19.
Gets a list of all keys that are assigned on any of the 4 setup pages for quick talk using the SELECT
control. Only keys that are assigned will be displayed.
LEVEL See “Top Level Menu, Level” on
page 19.
Lets you adjust the listen level for any key assigned to an intercom port or party line.
LISTS See “Top Level Menu, Lists” on page 19.
ICOM Appears only in trunked intercoms. Lets you log onto another intercom system.
PL Accesses the party line list to talk using SELECT control when desired party line is not assigned
to a key.
IFB Accesses the IFB list for quick talk using SELECT control when desired IFB is not assigned to a
key.
IFSL Accesses the IFSL list to talk using SELECT control when desired IFSL is not assigned to a key.
ISO Accesses the ISO list for quick talk using SELECT control when desired ISO is not assigned to a
key.
P-P Accesses the point-to-point list to talk using SELECT control when desired destination is not
assigned to a key.
RLY Accesses the intercom system’s list of relays to talk using SELECT control when desired relay is
not assigned to a key.
SPCL Accesses the special lists to talk using SELECT control when desired special list is not assigned
to a key.
UPL Access the intercom system’s list of UPL resources.
MENUS See “Top Level Menu, Menus” on
page 22.
Accesses less often used features. (See,“MENU MODE See “Menu Mode” on page 25.” on page 4.)
