Intercom System User Manual

Menu Mode
32
4. Tap SELECT.
The call waiting window will display TAP KEY.
5. Tap an intercom key to assign the party line.
If restrictions against key assignments have been imposed using the intercom system configuration software, the intercom key
may ignore the key assignment. In this case, contact the intercom system administrator if you need to make a change.
P-P key assignment has no effect on any key options that may already be assigned to that key using “General Description” on
page 35.
Changing a key’s assignment has no effect on any key options that may already be assigned to that key using “General
Description” on page 35.
6. Double-tap the SELECT control to return to the previous menu level. Or, press and hold the SELECT control for two
seconds to exit menu mode.
Menus, KEY ASGN, LISTS, RLY (Relays)
RLY can be used to assign relays in an FR9528 or UIO-256 Frame. It may also be used to assign the GPI outputs on the back
of an ADAM CS frame (J903) or on an XCP-ADAM-MC Master Controller Breakout Panel in an ADAM intercom system
(J11).
1. When you select RLY, the relay scroll list will appear in the call waiting window.
2. Turn the SELECT control to display the desired relay, then tap SELECT.
3. Turn the SELECT control to select one of the available key assignment options (talk level one, talk level two, or listen)
then, tap SELECT.
The call waiting window will display TAP KEY.
4. Tap an intercom key to assign the relay.
If restrictions against key assignment key assignments have been imposed using the intercom system configuration software,
the intercom key may ignore the key assignment. In this case, contact the intercom system administrator if you need to make a
change.
Relay key assignments are automatically uploaded to the intercom system and saved to the online configuration.
Changing a key’s assignment has no effect on any key options that may already be assigned to that key using“General
Description” on page 35.
5. Double-tap the SELECT control to return to the previous menu level. Or, press and hold the SELECT control for two
seconds to exit menu mode.
Menus, KEY ASGN, LISTS, SPCL (Special Lists)
1. When you select SPCL, the special list scroll list will appear in the call waiting window.
2. Turn the SELECT control to display the desired relay, then tap SELECT.
3. Turn the SELECT control to select one of the available key assignment options (talk level one, talk level two, or listen)
then, tap SELECT.
The call waiting window will display TAP KEY.
4. Tap an intercom key to assign the special list.
If restrictions against key assignment key assignments have been imposed using the intercom system configuration software,
the intercom key may ignore the key assignment. In this case, contact the intercom system administrator if you need to make a
change.
SPCL key assignments are automatically uploaded to the intercom system and saved to the online configuration.
