Owner`s manual

3.2.3 Weights All weights in kilograms (Kg)
Unladen Weight of craft (lightweight) without engine 160
Maximum Number of Persons 160
Heaviest allowable outboard motor 40
Portable fuel tanks 0
Baggage, outboard, & other carry-on weights 120
Max Load as on Builder's Plate 320 320
Essential safety equipment & life-raft 10
Weight of Fluids & Permanent Load 10 10
Maximum Recommended Load 330 330
Weight Fully Laden 490
Note: the weight of the outboard engine supplied with the boat is a maximum: 38kg
4 SYSTEMS DESCRIPTIONS
4.1 Bilge Pumps
This boat is not fitted with any bilge pumps.
It is recommended that a bailer is carried aboard for emergency bailing purposes. Ensure
the bailer is protected against accidental loss.
Warning
Never use flammable solvents (i.e. kerosene) for bilge cleaning, however
oily it becomes.
4.2 Electrical System
ALWAYS......
•
Check battery and charging system condition before going to sea
•
Disconnect and remove the battery when the craft is in winter storage (cold weather
areas) or long term storage
NEVER........
•
Work on the electrical installation while the system is energised;
•
Modify the craft's electrical system or relevant drawings: installation, alterations and
maintenance should be performed by a competent marine electrical technician;
• Alter or modify the rated current amperage of over-current protective devices;
• Install or replace electrical appliances or devices with components exceeding the rated
current amperage of the circuit;
