Product Manual

Model: 41360

Rotary Pump Kit for

40549/42859 Gas Caddy

REV03/14

OPERATOR’S MANUAL 41360 ROTARY PUMP KIT

Operation

1. Connect the ground wire clamp the container or to a known ground on the vehicle receiving the fuel.

2. Position the dispensing hose in the container or vehicle that is receiving the fuel.

3. Open the ball valve on the gas caddy.

4. Open the vent on the fill cap.

5. Turn the handle clockwise to dispense fuel.

6. Monitor flow and liquid level to prevent spills

To close for storage

1. When finished return remaining fuel back into the tank by laying the tank in the horizontal position, open ball vavle and raise

the hose rotate the pump handle counter-clockwise to allow fuel to return to the tank.

2. Close the ball valve by turning the valve handle until it stops in the 90 ° position.

3. Turn vent until it is closed, then turn an additional 1/8 turn.

4. Return to upright vertical position

Transportation

1. Remove the pump and bracket by loosening the knob and turning the J-hook bracket to release the pump from the gas caddy.

2. Place beside the gas caddy and secure with straps.

Distributed by

Northern Tool + Equipment Co., Inc.

Burnsville, Minnesota 55306

NorthernTool.com

Made in U.S.A.

For replacement parts

and technical questions,

please call

1-800-222-5381.

WARRANTY

1-year limited warranty

PAGE 1
OPERATOR’S MANUAL 41360 ROTARY PUMP KIT Operation 1. Connect the ground wire clamp the container or to a known ground on the vehicle receiving the fuel. 2. Position the dispensing hose in the container or vehicle that is receiving the fuel. 3. Open the ball valve on the gas caddy. 4. Open the vent on the fill cap. 5. Turn the handle clockwise to dispense fuel. 6. Monitor flow and liquid level to prevent spills To close for storage 1.
PAGE 2
OPERATOR’S MANUAL 41360 ROTARY PUMP KIT INSTRUCTIONS PERTAINING TO THE RISK OR INJURY TO PERSONS. OPERATOR’S MANUAL 41360 ROTARY PUMP KIT ASSEMBLY Pump and bracket assembly instructions IMPORTANT SAFETY INSTRUCTIONS. SAVE THESE INSTRUCTIONS. READ THIS MANUAL CAREFULLY BEFORE INSTALLING, OPERATING OR SERVICING THIS EQUIPMENT It is the responsibility of the employer to place this information in the hands of the operator. Keep for future reference. 1.
